Job 1 and Job 2 standard-range configurations
The 2023 model year crosses a battery-chemistry transition.
- Job 1 70-kWh usable NCM.
- Job 2 72-kWh usable LFP.
- June 26 Job 2 date subject to change.
- No inferred LFP-AWD final EPA record.
Mustang Mach-E, 2023 NCM/LFP transition phase
2023 Ford Mustang Mach-E Facts
The 2023 Mustang Mach-E crossed from its original NCM standard-range pack to a 72-kWh usable LFP pack during Job 2, while final U.S. certification retained eight distinct records and Ford announced future adapter access to Tesla Superchargers.
Image Gallery
Image rights & changes
- Creator
- MoCars
- Exact source
- Open source record
- Use basis
- CC0
- Changes
- Auto-oriented, resized, and metadata removed for web display.
Image rights & changes
- Creator
- MoCars
- Exact source
- Open source record
- Use basis
- CC0
- Changes
- Auto-oriented, resized, and metadata removed for web display.
Image rights & changes
- Creator
- MoCars
- Exact source
- Open source record
- Use basis
- CC0
- Changes
- Auto-oriented, resized, and metadata removed for web display.
Sales & Production Scope
Cuautitlán calendar-year production: 94,465
94,465
Ford Motor Company Q4 and full-year 2023 U.S. Sales
Ford-reported Mustang Mach-E production during calendar year 2023. Ford reports no January production during plant retooling. This is calendar-year plant output, not final 2023-model-year production.
40,771
Ford Motor Company Q4 and full-year 2023 U.S. Sales
Ford-reported United States calendar-year 2023 sales of Mustang Mach-E. Sales are deliveries, not production, and cannot be added to Cuautitlán output.
Ford's calendar-year Cuautitlán output and United States sales have incompatible scopes. Plant output is not a model-year total, and sales are deliveries rather than production.
What It Is
- Ford's Job 2 guide changed Select and Premium standard-range usable capacity from 70 to 72 kWh for vehicles effective June 26, 2023, subject to change.
- FuelEconomy.gov catalogs seven pre-LFP configurations and one separately named LFP RWD configuration; Ford identifies NCM as the existing Mach-E chemistry before the planned 2023 North American LFP addition. No distinct final LFP-AWD record appeared in the inspected menu.
- Ford's 72-kWh LFP sheet targeted 226 miles for standard-range eAWD, but a target does not replace a final certification record.
- Ford announced future adapter and software access to Tesla Superchargers in May 2023; the announcement did not change a 2023 vehicle's CCS charge port.
Power, Battery & Range
| Trim / Drivetrain | Battery / Motor | Drive | HP | Torque | EPA range | Efficiency | Charging | EPA record |
|---|---|---|---|---|---|---|---|---|
| Early Standard Range AWD NCM | 75.7 kWh gross / 70 kWh usable NCM dual permanent-magnet motors | All-wheel drive | 266 | 428 | 224 miles | 93 MPGe · 36.3182 kWh/100 mi | 8.0 hr Level 2 · up to 115 kW DC | EPA record 46512 |
| Extended Range AWD | 98.8 kWh gross / 91 kWh usable NCM dual permanent-magnet motors | All-wheel drive | 346 | 428 | 290 miles | 92 MPGe · 36.7996 kWh/100 mi | 10.0 hr Level 2 · up to 150 kW DC | EPA record 46513 |
| California Route 1 AWD | 98.8 kWh gross / 91 kWh usable NCM dual permanent-magnet motors | All-wheel drive | 346 | 428 | 312 miles | 98 MPGe · 34.3412 kWh/100 mi | 10.1 hr Level 2 · up to 150 kW DC | EPA record 46514 |
| GT AWD | 98.8 kWh gross / 91 kWh usable NCM dual-motor GT performance system | All-wheel drive | 480 | 600 | 270 miles | 84 MPGe · 40.1838 kWh/100 mi | 10.3 hr Level 2 · up to 150 kW DC | EPA record 46515 |
| GT Performance Edition | 98.8 kWh gross / 91 kWh usable NCM dual-motor GT Performance system | All-wheel drive | 480 | 634 | 260 miles | 82 MPGe · 41.0 kWh/100 mi | 10.1 hr Level 2 · up to 150 kW DC | EPA record 46516 |
| Early Standard Range RWD NCM | 75.7 kWh gross / 70 kWh usable NCM single rear permanent-magnet motor | Rear-wheel drive | 266 | 317 | 247 miles | 103 MPGe · 32.6522 kWh/100 mi | 8.1 hr Level 2 · up to 115 kW DC | EPA record 46517 |
| Extended Range RWD | 98.8 kWh gross / 91 kWh usable NCM single rear permanent-magnet motor | Rear-wheel drive | 290 | 317 | 310 miles | 99 MPGe · 34.0119 kWh/100 mi | 10.2 hr Level 2 · up to 150 kW DC | EPA record 46518 |
| Job 2 Standard Range RWD LFP | 72 kWh usable LFP; gross capacity not established single rear permanent-magnet motor | Rear-wheel drive | 266 | 317 | 250 miles | 101 MPGe · 33.3071 kWh/100 mi | 7.4 hr Level 2 · up to 150 kW DC | EPA record 46985 |
Options & Packages
Availability does not establish how many were built. Counts remain explicitly unknown where Ford did not publish them.
| Trim or package | Ford code | Availability | Units | Count status |
|---|---|---|---|---|
| Select Entry trim spanning the chemistry transition. | 100A | Standard-range RWD or eAWD; 70-kWh NCM at Job 1 and 72-kWh LFP at Job 2. | Not publicly published | No public total found |
| California Route 1 Range-focused eAWD configuration. | 200A | 91-kWh usable extended-range eAWD only. | Not publicly published | No public total found |
| Premium Broadest battery and drivetrain catalog. | 300A | Standard- or extended-range battery with RWD or eAWD, subject to Job phase. | Not publicly published | No public total found |
| GT The 480-hp performance branch. | 400A | 91-kWh usable extended-range battery and dual-motor eAWD. | Not publicly published | No public total found |
| GT Performance Edition Factory performance upgrade for GT. | 60P | GT-based performance package with 634 lb-ft, MagneRide, and dedicated seats and wheels. | Not publicly published | No public total found |
| Mustang Nite Pony Package Factory blackout appearance package. | 55R | Optional on Premium Extended Range and GT Performance Edition with configuration-specific black wheels and badges. | Not publicly published | No public total found |
Trim & Package Details
GT Performance Edition and Mustang Nite Pony
Performance and appearance packages remain distinct.
- GT Performance Edition 60P.
- Mustang Nite Pony 55R.
- No published completed counts.
Safety & service records
These United States year/make/model matches show campaign applicability, not whether a particular VIN still needs a remedy. Check the vehicle with the Ford VIN recall lookup and NHTSA VIN recall lookup. Imported from NHTSA on July 31, 2026.
The dated local import found 5 recall campaigns, 115 unique ODI owner reports, 2 investigations, and 178 manufacturer communications.
Ford vehicle recall campaigns
| Campaign | Received | Component |
|---|---|---|
| 24V594000 | Aug 9, 2024 | VISIBILITY:WINDSHIELD WIPER/WASHER:MOTOR |
Campaign detailsFord Motor Company (Ford) is recalling certain 2023-2024 Maverick, Ford Bronco Sport, and Mustang Mach-E vehicles. The front windshield wiper motor may become inoperative, causing the wipers to fail. Consequence: Inoperative windshield wipers can reduce visibility in certain conditions, increasing the risk of a crash. Remedy: Dealers will inspect and replace the windshield wiper motor as necessary, free of charge. Owner notification letters were mailed on December 6, 2024. Owners may contact Ford customer service at 1-866-436-7332. Ford's number for this recall is 24S51. |
||
| 25V315000 | May 9, 2025 | BACK OVER PREVENTION:SOFTWARE |
Campaign detailsFord Motor Company (Ford) is recalling certain 2021-2024 Bronco, F-150, 2021-2024 Edge, 2022-2025 Escape, F-250, F-350, F-450, F-550, F-600, 2022-2024 Expedition, 2022-2025 Transit, 2021-2023 Mach-E, 2024 Ranger, Mustang, 2021-2023 Lincoln Nautilus, 2022-2024 Navigator, and 2023-2024 Corsair vehicles. A software error may cause the rearview camera image to delay, freeze, or not display when the vehicle is in reverse. Consequence: A frozen or missing rearview camera image can reduce the driver's view behind the vehicle, increasing the risk of a crash. Remedy: The accessory protocol interface module (APIM) software will be updated by a dealer or through an over-the-air update, free of charge. This will be a phased campaign, with the remedy becoming available in different phases based on model and model years. Interim letters notifying owners of the safety risk were mailed on June 26, 2025. Additional letters will be mailed once the final remedy is available on each phase. Owner notification letters were sent on October 8, 2025. Owners may contact Ford customer service at 1-866-436-7332. Ford's number for this recall is 25S49. |
||
| 25V404000 | Jun 13, 2025 | ELECTRICAL SYSTEM:BODY CONTROL MODULE:SOFTWARE |
Campaign detailsFord Motor Company (Ford) is recalling certain 2021-2025 Mustang Mach E vehicles. In the event of a low battery charge, the electronic door latches may remain locked once the driver or front passenger exits and shuts the door, possibly trapping someone who is unable to use the inside door release handles, such as a child in the back seat. Consequence: The inability to enter or exit the vehicle in an emergency increases the risk of injury. Remedy: Dealers will update the Powertrain Control Module (PCM) and the Secondary On-Board Diagnostic Control Module C (SOBDMC) software, free of charge. Owner notification letters were mailed to 2021-2025 Mustang Mach-E owners September 12, 2025. Additionally, Owner notification letters were mailed to 2024-2025 Mustang Mach-E owners July 10, 2025. Owners may contact Ford customer service at 1-866-436-7332. Ford's number for this recall is 25S65. |
||
| 26V417000 | Jun 30, 2026 | POWER TRAIN:DRIVELINE:DIFFERENTIAL UNIT |
Campaign detailsFord Motor Company (Ford) is recalling certain 2021-2023 Mustang Mach E vehicles. The rear differential pinion shaft may fracture. Consequence: Differential pinion shaft fracture may result in a loss of drive power, or unintended vehicle movement if the vehicle is in park without the parking brake applied, increasing the risk of a crash. Remedy: Dealers will repair or replace the rear differential assembly as necessary, free of charge. Interim letters, notifying owners of the safety risk, were mailed July 13, 2026. Additional letters will be sent once the remedy is available, anticipated in late December 2026. Owners may contact Ford customer service at 1-866-436-7332. Ford's number for this recall is 26S50. |
||
| 26V487000 | Jul 28, 2026 | STRUCTURE:EXTERIOR TRIM |
Campaign detailsFord Motor Company (Ford) is recalling certain 2023-2025 Mustang Mach E vehicles. The rear side quarter window glass trim may be improperly secured, which can allow it to detach. Consequence: Detached trim pieces can create a road hazard, increasing the risk of a crash. Remedy: Dealers will inspect and replace the quarter window glass assemblies, as necessary, free of charge. Interim letters, notifying owners of the safety risk, are expected to be mailed September 10, 2026. Additional letters will be sent once the remedy is available. Owners may contact Ford customer service at 1-866-436-7332. Ford's number for this recall is 26S56. Vehicle Identification Numbers (VINs) involved in this recall will be searchable on NHTSA.gov beginning September 7, 2026. |
||
NHTSA investigations
EA25001 — Collisions Involving Ford BlueCruise
ELECTRICAL SYSTEM:ADAS · Open · opened Jan 17, 2025
Investigation details
On April 25, 2024, NHTSA’s Office of Defects Investigation (ODI) opened a Preliminary Evaluation (PE24012) to assess BlueCruise, a partial driving automation system available on certain vehicles manufactured by Ford Motor Company (Ford). NHTSA opened the investigation after the agency received notice of two fatal collisions involving BlueCruise-equipped Ford Mustang Mach-E vehicles. Based on the incidents, NHTSA scoped the investigation to 2021-2024 Mustang Mach-E vehicles equipped with BlueCruise. In June 2024, ODI sent an Information Request (IR) letter to Ford requiring that it provide certain information pertaining to crashes, non-crash reports, and technical specifications that relate to BlueCruise, as well as other Ford partial driving automation systems that offer lane and speed maintenance. In its response to ODI’s IR, Ford stated that there are 2,539,962 Ford and Lincoln vehicles (including subject and peer vehicles) equipped with a partial driving automation system within the scope of the request. The majority of these vehicles are equipped with a system that Ford calls Lane Centering Assist (LCA), which is a hands-on partial driving automation system that combines longitudinal control authority governed by Adaptive Cruise Control (ACC) and lateral control authority governed by a steerable path. LCA is offered on a wide range of Ford and Lincoln models beginning in model year 2019. Vehicles that are equipped with BlueCruise, the focus of this investigation, have LCA capability and additionally offer hands-free partial driving automation when certain conditions are met. Hands-free BlueCruise operation is only offered on certain roadways and system availability is geofenced using vehicle GPS. BlueCruise-equipped vehicles employ a camera-based driver monitoring system to determine driver attentiveness to the roadway. BlueCruise was introduced in model year 2021 and is currently available in a select range of Ford and Lincoln vehicles. For BlueCruise- and LCA-equipped vehicles, both ACC and Pre-Collision Assist (PCA) features use a combination of camera and radar sensing technologies to detect and classify objects. ACC is specifically designed to detect vehicles (including cars, trucks, and motorcycles) and bicycles in front of the subject vehicle which are either stationary or moving in the same direction as the subject vehicle. Through this investigation, limitations in the detection of stationary vehicles in certain conditions have been identified. Specifically, due to the potential for false detection of stationary objects at long distances, Ford designed ACC to inhibit any response to reported stationary objects when the subject vehicle’s approach speed is at or above 62 mph. Additionally, system performance may be limited when there is poor visibility due to insufficient illumination. In addition to reviewing Ford’s response to ODI’s IR, the agency conducted a review of crash and non-crash reports identified collectively through Ford’s IR response, incident reporting through Standing General Order 2021-01 (SGO), and NHTSA vehicle owner questionnaires. In total, 32 crashes and 2,004 non-crash reports on subject and peer Ford vehicles were identified across manufacturer and ODI data sources. A detailed analysis of each crash was conducted including the review of any available police reports, photographs, data recovered from in-vehicle event data recorders, connected vehicle data, and/or other information. In both fatal collisions referenced in the PE24012 opening resume, the subject Ford Mustang Mach-E vehicle was traveling over 70 mph on a controlled-access highway during nighttime lighting conditions with hands-free BlueCruise engaged when it collided with a stationary vehicle. Analysis of data imaged from the vehicles’ event data recorders demonstrates that in each incident, the driver did not apply the brakes or take evasive steering action, and no deceleration was initiated by either the BlueCruise system or PCA prior to impact. Through the agency’s crash analysis, four additional frontal collisions were identified where the subject Ford impacted a stopped or slow-moving lead vehicle or another stationary object located in the travel lane. Two of these four incidents involved BlueCruise-equipped Ford Mustang Mach-E vehicles (included in the failure report summary along with the fatal collisions discussed above), while the other two involved other Ford models equipped with the LCA system. Additionally, a trend was identified through analysis of the non-crash reports relating to allegations that ACC (the longitudinal component of both BlueCruise and LCA) failed to detect and/or respond to a stopped or slow-moving lead vehicle. In these reports, consumers often describe that the absence of deceleration initiated by ACC was unexpected and required harsh manual braking or intervention from the PCA to avoid a frontal collision with the lead vehicle. Based on NHTSA’s analysis, system limitations relating to the detection of stationary vehicles while traveling at highway speeds and in nighttime lighting conditions appear to be factors in collisions under investigation and several apparently similar near-miss, non-crash reports. This Engineering Analysis (EA) is being opened to further investigate these system limitations and to evaluate drivers’ ability to respond to scenarios that exceed system limitations. During the EA, the agency expects to, among other things, perform vehicle evaluations, review additional technical information, and perform additional analysis of related crashes and non-crash reports. The crashes included in the failure report summary can be found at NHTSA.gov under the following SGO report identification numbers: 502-7268, 502-7426, 502-6852, 502-8738.
PE24012 — Collisions Involving Ford BlueCruise
ELECTRICAL SYSTEM:ADAS · Closed · opened Apr 25, 2024 · closed Jan 17, 2025
Investigation details
On April 25, 2024, NHTSA’s Office of Defects Investigation (ODI) opened a Preliminary Evaluation (PE24012) to assess BlueCruise, a partial driving automation system available on certain vehicles manufactured by Ford Motor Company (Ford). NHTSA opened the investigation after the agency received notice of two fatal collisions involving BlueCruise-equipped Ford Mustang Mach-E vehicles. Based on the incidents, NHTSA scoped the investigation to 2021-2024 Mustang Mach-E vehicles equipped with BlueCruise. In June 2024, ODI sent an Information Request (IR) letter to Ford requiring that it provide certain information pertaining to crashes, non-crash reports, and technical specifications that relate to BlueCruise, as well as other Ford partial driving automation systems that offer lane and speed maintenance. In its response to ODI’s IR, Ford stated that there are 2,539,962 Ford and Lincoln vehicles (including subject and peer vehicles) equipped with a partial driving automation system within the scope of the request. The majority of these vehicles are equipped with a system that Ford calls Lane Centering Assist (LCA), which is a hands-on partial driving automation system that combines longitudinal control authority governed by Adaptive Cruise Control (ACC) and lateral control authority governed by a steerable path. LCA is offered on a wide range of Ford and Lincoln models beginning in model year 2019. Vehicles that are equipped with BlueCruise, the focus of this investigation, have LCA capability and additionally offer hands-free partial driving automation when certain conditions are met. Hands-free BlueCruise operation is only offered on certain roadways and system availability is geofenced using vehicle GPS. BlueCruise-equipped vehicles employ a camera-based driver monitoring system to determine driver attentiveness to the roadway. BlueCruise was introduced in model year 2021 and is currently available in a select range of Ford and Lincoln vehicles. For BlueCruise- and LCA-equipped vehicles, both ACC and Pre-Collision Assist (PCA) features use a combination of camera and radar sensing technologies to detect and classify objects. ACC is specifically designed to detect vehicles (including cars, trucks, and motorcycles) and bicycles in front of the subject vehicle which are either stationary or moving in the same direction as the subject vehicle. Through this investigation, limitations in the detection of stationary vehicles in certain conditions have been identified. Specifically, due to the potential for false detection of stationary objects at long distances, Ford designed ACC to inhibit any response to reported stationary objects when the subject vehicle’s approach speed is at or above 62 mph. Additionally, system performance may be limited when there is poor visibility due to insufficient illumination. In addition to reviewing Ford’s response to ODI’s IR, the agency conducted a review of crash and non-crash reports identified collectively through Ford’s IR response, incident reporting through Standing General Order 2021-01 (SGO), and NHTSA vehicle owner questionnaires. In total, 32 crashes and 2,004 non-crash reports on subject and peer Ford vehicles were identified across manufacturer and ODI data sources. A detailed analysis of each crash was conducted including the review of any available police reports, photographs, data recovered from in-vehicle event data recorders, connected vehicle data, and/or other information. In both fatal collisions referenced in the PE24012 opening resume, the subject Ford Mustang Mach-E vehicle was traveling over 70 mph on a controlled-access highway during nighttime lighting conditions with hands-free BlueCruise engaged when it collided with a stationary vehicle. Analysis of data imaged from the vehicles’ event data recorders demonstrates that in each incident, the driver did not apply the brakes or take evasive steering action, and no deceleration was initiated by either the BlueCruise system or PCA prior to impact. Through the agency’s crash analysis, four additional frontal collisions were identified where the subject Ford impacted a stopped or slow-moving lead vehicle or another stationary object located in the travel lane. Two of these four incidents involved BlueCruise-equipped Ford Mustang Mach-E vehicles (included in the failure report summary along with the fatal collisions discussed above), while the other two involved other Ford models equipped with the LCA system. Additionally, a trend was identified through analysis of the non-crash reports relating to allegations that ACC (the longitudinal component of both BlueCruise and LCA) failed to detect and/or respond to a stopped or slow-moving lead vehicle. In these reports, consumers often describe that the absence of deceleration initiated by ACC was unexpected and required harsh manual braking or intervention from the PCA to avoid a frontal collision with the lead vehicle. Based on NHTSA’s analysis, system limitations relating to the detection of stationary vehicles while traveling at highway speeds and in nighttime lighting conditions appear to be factors in collisions under investigation and several apparently similar near-miss, non-crash reports. This Preliminary Evaluation is being upgraded to an Engineering Analysis (EA25001) to further investigate these system limitations and to evaluate drivers’ ability to respond to scenarios that exceed system limitations. During the EA, the agency expects to, among other things, perform vehicle evaluations, review additional technical information, and perform additional analysis of related crashes and non-crash reports. The crashes included in the failure report summary can be found at NHTSA.gov under the following SGO report identification numbers: 502-7268, 502-7426, 502-6852, 502-8738.
Owner complaint reports
NHTSA returned 115 rows. After exact vehicle-scope filtering, 115 rows represent 115 unique ODI owner reports. Repeated ODI rows can describe separate components of one report and are not double-counted.
Complaints are attributed reports, not verified defects or failure rates. Reported crashes, fires, injuries, and deaths can overlap and do not establish causation.
- Reported crashes
- 8
- Reported fires
- 1
- Reported injuries
- 3
- Reported deaths
- 0
Complaint component counts
| NHTSA component label | Unique reports |
|---|---|
| ELECTRICAL SYSTEM | 14 |
| SERVICE BRAKES | 12 |
| UNKNOWN OR OTHER | 9 |
| POWER TRAIN,ELECTRICAL SYSTEM | 8 |
| ELECTRICAL SYSTEM,FUEL/PROPULSION SYSTEM | 3 |
| ELECTRICAL SYSTEM,UNKNOWN OR OTHER | 3 |
| STRUCTURE | 3 |
| VEHICLE SPEED CONTROL | 3 |
| AIR BAGS,FORWARD COLLISION AVOIDANCE | 2 |
| ELECTRICAL SYSTEM,ENGINE,FUEL/PROPULSION SYSTEM | 2 |
| ELECTRICAL SYSTEM,LATCHES/LOCKS/LINKAGES | 2 |
| FORWARD COLLISION AVOIDANCE,LANE DEPARTURE | 2 |
| POWER TRAIN | 2 |
| POWER TRAIN,ELECTRICAL SYSTEM,ENGINE | 2 |
| POWER TRAIN,ELECTRICAL SYSTEM,FUEL/PROPULSION SYSTEM | 2 |
| SERVICE BRAKES, HYDRAULIC | 2 |
| SERVICE BRAKES,FORWARD COLLISION AVOIDANCE | 2 |
| UNKNOWN OR OTHER,FUEL/PROPULSION SYSTEM | 2 |
| UNKNOWN OR OTHER,SERVICE BRAKES | 2 |
| VEHICLE SPEED CONTROL,FORWARD COLLISION AVOIDANCE | 2 |
| AIR BAGS,SEAT BELTS,SEATS | 1 |
| BACK OVER PREVENTION | 1 |
| ELECTRICAL SYSTEM,AIR BAGS | 1 |
| ELECTRICAL SYSTEM,BACK OVER PREVENTION | 1 |
| ELECTRICAL SYSTEM,BACK OVER PREVENTION,FORWARD COLLISION AVOIDANCE | 1 |
| ELECTRICAL SYSTEM,EXTERIOR LIGHTING,UNKNOWN OR OTHER | 1 |
| ELECTRICAL SYSTEM,SEATS,FORWARD COLLISION AVOIDANCE | 1 |
| ELECTRICAL SYSTEM,UNKNOWN OR OTHER,FORWARD COLLISION AVOIDANCE | 1 |
| ELECTRICAL SYSTEM,VEHICLE SPEED CONTROL | 1 |
| ENGINE | 1 |
| ENGINE,FORWARD COLLISION AVOIDANCE | 1 |
| FORWARD COLLISION AVOIDANCE | 1 |
| FORWARD COLLISION AVOIDANCE,ELECTRICAL SYSTEM | 1 |
| FUEL/PROPULSION SYSTEM | 1 |
| LANE DEPARTURE,BACK OVER PREVENTION,FORWARD COLLISION AVOIDANCE | 1 |
| LATCHES/LOCKS/LINKAGES | 1 |
| POWER TRAIN,ELECTRICAL SYSTEM,AIR BAGS | 1 |
| POWER TRAIN,ELECTRICAL SYSTEM,UNKNOWN OR OTHER | 1 |
| POWER TRAIN,ELECTRICAL SYSTEM,VEHICLE SPEED CONTROL | 1 |
| POWER TRAIN,SERVICE BRAKES,FORWARD COLLISION AVOIDANCE | 1 |
| POWER TRAIN,SERVICE BRAKES,FUEL/PROPULSION SYSTEM | 1 |
| POWER TRAIN,UNKNOWN OR OTHER | 1 |
| POWER TRAIN,UNKNOWN OR OTHER,ENGINE | 1 |
| SEAT BELTS | 1 |
| SERVICE BRAKES,LANE DEPARTURE,FORWARD COLLISION AVOIDANCE | 1 |
| STEERING,ELECTRICAL SYSTEM,UNKNOWN OR OTHER | 1 |
| STEERING,LANE DEPARTURE,FORWARD COLLISION AVOIDANCE | 1 |
| STEERING,SERVICE BRAKES,FORWARD COLLISION AVOIDANCE | 1 |
| STEERING,VEHICLE SPEED CONTROL | 1 |
| STEERING,VEHICLE SPEED CONTROL,FORWARD COLLISION AVOIDANCE | 1 |
| STRUCTURE,VISIBILITY/WIPER | 1 |
| TIRES | 1 |
| UNKNOWN OR OTHER,EQUIPMENT | 1 |
| UNKNOWN OR OTHER,SERVICE BRAKES,FORWARD COLLISION AVOIDANCE | 1 |
| VEHICLE SPEED CONTROL,FUEL/PROPULSION SYSTEM | 1 |
| VEHICLE SPEED CONTROL,UNKNOWN OR OTHER | 1 |
Manufacturer communications and TSBs
The local NHTSA import found 178 manufacturer communications whose published model-year field includes this Mustang.
Manufacturer communications include service bulletins, owner notices, service messages, and other manufacturer submissions. They are not recalls or proof of a defect, and a catalog match does not prove that one document applies to a particular VIN.
Browse manufacturer communications
| NHTSA document ID | Published model years | Concise summary |
|---|---|---|
| 10228876 | 2021,2022,2023 | Some Ford and Lincoln vehicles may exhibit noise when the brakes are applied. When diagnosing and repairing brake noise conditions, use the Workshop Manual (WSM) and the appropriate pinpoint test in section 206-00. The brake rotors should only be machined if directed by the WSM because one or more of the following conditions are present on the braking surface: scoring, excessive corrosion/rust or pitting, bluing/discoloration and/or heat spots. For additional information, refer to WSM section 206-00. |
| 10230789 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a false alarm activation and/or warning message in the FordPass application when the doors are locked. This may be due to the software in the door latch control module E (DCME), door latch control module F (DCMF), door latch control module G (DCMG) and/or door latch control module H (DCMH). To correct the condition, download and run the door control module software update application for each module one at a time using the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 58219A65 and applicable labor times in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10230944 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may experience minor damage to the high voltage battery (HVB) tray as a result of coming contact with road debris and/or other outside influences. Workshop Manual (WSM), Section 414-03A has been updated to include new topics for inspection, repair and replacement of the HVB tray. These new topics should be used to help determine severity of damage and an appropriate repair direction for the HVB tray. If inspection per the WSM determines that the HVB tray requires replacement, the HVB battery trays for standard and extended range have been released for service as a lower cost repair option. Standard range HVB tray - LJ9Z-10732-E. Extended range HVB tray - LJ9Z-10732-D. |
| 10231323 | 2021,2022,2023 | Priority Update 23-PU0105-DC-CHG2 for 2021- 2023 Mach E vehicles is now available. Quality improvements include: - Improvement to DC Fast Charging functionality. |
| 10233580 | 2021,2022,2023 | This article supersedes TSB 22-2355 to update the vehicle model years affected. Some 2021-2023 Mustang Mach-E, 2022-2023 e-Transit and F-150 Lightning vehicles may experience inoperative level 3 charging with an illuminated Charger Service Required indicator in the instrument panel cluster (IPC) and diagnostic trouble codes (DTCs) P0D93:00, P0D94:00, P0D98:00, P0D9E:00 and/or P0DA0:00 in the secondary on-board diagnostic module (SOBDM). If the charging cord is removed from the charge port without the lock/release button fully pressed, this can damage the charge port locking pin actuator and disable level 3 charging for the next charging session. To correct the condition, follow the Service Procedure to replace only the charge port lock actuator. |
| 10233596 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a lack/loss of heat and/or windshield interior fogging while driving during freezing temperatures. This may be due to the heating ventilation and air conditioning (HVAC) control module software. To correct the condition, follow the Service Procedure to update the HVAC control module software. |
| 10233921 | 2021,2022,2023 | Some 2021-2023 Ford and Lincoln vehicles may exhibit a condition where the high voltage battery stops charging when connected to level 1 or level 2 chargers with an illuminated malfunction indicator lamp (MIL) and diagnostic trouble code (DTC) P2C94 stored in the secondary on-board diagnostic control module A (SOBDM). To restore charging capability, disconnect the off-board charging station charge handle from the vehicle charge port and reconnect. This condition does not affect vehicle durability and no additional diagnosis or service is required for this condition at this time. Inform customers that they can continue to drive the vehicle and engineering is currently working on a solution for this condition that is expected in June 2023. Replacement of the SOBDM will not resolve this condition. Monitor OASIS for additional information. |
| 10233943 | 2023 | Priority Update 23-PU0210-ALBC_ON for 2023 Mach E vehicles is now available. Quality Improvements include: - Improved customer experience for Lane Change Assist and In-Lane Repositioning features. |
| 10234595 | 2021,2022,2023 | Some 2021-2023 F-150/Mustang Mach-E and 2023 Expedition/Navigator vehicles equipped with BlueCruise/ActiveGlide may experience loss of BlueCruise/ActiveGlide hands-free driving mode availability and/or BlueCruise/ActiveGlide inoperative and/or diagnostic trouble code (DTC) U2400:00 in the gateway module (GWM) and advanced driver assistance system (ADAS) modules with no other DTCs present. This may be due to an expired BlueCruise/ActiveGlide map file in the GWM and/or the customer's BlueCruise/ActiveGlide map subscription being expired. To correct the condition, follow the Service Procedure to update the GWM. |
| 10235084 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles built on or before 16-Feb-2023 may exhibit a false alarm activation and/or warning message in the FordPass application when the doors are locked. This may be due to the software in the door latch control module E (DCME), door latch control module F (DCMF), door latch control module G (DCMG) and/or door latch control module H (DCMH). To correct the condition, download and run the door control module software update application for each module one at a time using the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 58219A65 and applicable labor times in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10235085 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may experience loss of phone as a key after an over the air (OTA) update. There may also be diagnostic trouble code (DTC) U0214 stored various modules for loss of communication with the remote function actuator (RFA) module. This may be due to software in the RFA module causing it be locked/stuck in programming mode. To restore phone as a key functionality for the customer and RFA communication, remove RFA fuse (F18/19) located in the body control module (BCM) for one minute and plug it back in. Reprogram the RFA module using the latest software level of the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 14G617 and applicable labor operations in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10235153 | 2021,2022,2023 | For 2000-2024 Ford and Lincoln vehicles, swapping a module from a vehicle for diagnosis purposes is likely to cause errors and is not recommended. It is also not recommended to order a replacement module using a vehicle identification number (VIN) from a different vehicle. Most modules on these affected vehicles are VIN/vehicle specific and hardware variations between modules do exist. Swapping a module from a vehicle or ordering a module using a different vehicle/VIN can cause ineffective repairs and additional vehicle down time. Make sure all appropriate Workshop Manual (WSM) procedures are followed when diagnosing the condition prior to all module replacements and only order modules using the correct VIN. |
| 10235741 | 2021,2022,2023 | Software Update 4 P1: For 2021- 2023 Model Year Mach E vehicles is now available. Quality improvements include: - Improved heater performance and interior humidity compensation. - Enhanced Power Steering Control Module communication. (Removes erroneous popup message) - Improvements to Lane Keeping Feature - Improvements in Cyber Security for Driver Assist Tech. |
| 10236023 | 2021,2022,2023 | Some 2021-2023 F-150/Mustang Mach-E/Edge vehicles may exhibit a concern of Android Auto unable to wirelessly connect and/or Android phones rebooting when connected to the vehicle via USB. This is due to a concern with the Google application on the customers device. Google has released a fix for these concerns. For Android phones not connecting wirelessly, request that the customer update their Android Auto version to 6.1 or later. For customers who's Android phone reboots when connected via USB, request that the customer update their Chrome application to 88.0.4324.181 or later. The customers service provider should be able to assist customers having difficulty updating their device. This is not a warrantable repair. |
| 10236030 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may experience minor damage to the high voltage battery (HVB) tray as a result of coming contact with road debris and/or other outside influences. Workshop Manual (WSM), Section 414-03A has been updated to include new topics for inspection, repair and replacement of the HVB tray. These new topics should be used to help determine severity of damage and an appropriate repair direction for the HVB tray. If inspection per the WSM determines that the HVB tray requires replacement, the HVB battery trays for standard and extended range have been released for service as a lower cost repair option. Standard range HVB tray - LJ9Z-10732-E. Extended range HVB tray - LJ9Z-10732-D. When an HVB tray is replaced, a new high voltage battery serial number label must be obtained as directed in the WSM and installed in the location indicated. |
| 10236035 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit various driver assistance system warning messages or inoperative features and/or Diagnostic Trouble Code (DTC) U3000:49 stored in the Image Processing Module A (IPMA) that will not clear and not be stored in the vehicle's history. DTC C1001:31 and/or U3000:89 may be stored in the IPMA, but may have recently been cleared and stored in the vehicle's history. This may be due to a connection issue between the IPMA Camera and the IPMA. To correct the condition, perform the following service procedure to repair the connection and reset the IPMA. |
| 10236333 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E, 2022-2023 F-150 Lightning vehicles may experience an exterior charge status indicator not illuminating the blue charging segments after an over the air (OTA) update. Confirm if the Charge Port Light toggle button is not present in the center display screen by selecting Vehicle Icon> Controls> Access> Charge Port Light toggle button, as this button has been removed after OTA update. Replacing the charge port and/or the battery charger control module (BCCM) is not recommended. This condition does not affect charge behavior and no additional diagnosis or service is required for this condition at this time. Inform customers that they can continue to drive the vehicle and engineering is currently working on a solution for this condition that is expected in September 2023. Monitor OASIS for additional information. |
| 10236577 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit various driver assistance system warning messages or inoperative features and/or diagnostic trouble code (DTC) U3000:49 stored in the image processing module A (IPMA) that will not clear and not be stored in the vehicle's history. DTCs C1001:31 and/or U3000:89 may be stored in the IPMA, but may have recently been cleared and stored in the vehicle's history. This may be due to a connection issue between the IPMA Camera and the IPMA. To correct the condition, perform the following service procedure to repair the connection and reset the IPMA. |
| 10237459 | 2021,2022,2023 | Software Update 4 P2 for 2021- 2023 Model Year Mach E vehicles is now available. Quality improvements include: Remove Reverse Brake Assist unavailable warning Remove Beltminder Tollbooth Mode Remove incorrect frunk service now pop- up. Improves hood ajar warnings/ chimes. New thermal parameters added for increased powertrain component protection. Ford Pass Charge settings - will not revert back to previous settings. |
| 10237467 | 2021,2022,2023 | Priority Update 23-PU0415-BLM-FX-VIS for 2021 - 2023 Mach E vehicles is now available Quality Improvements include: -Phone as a Key Passive Entry improvement |
| 10237471 | 2023 | Priority Update 23-PU0105-DC-CHG2 for 2023 Mach E vehicles is now available: Quality Improvements include: -Improvements to the DC Fast Charging experience. |
| 10237585 | 2023 | Some 2023 Mustang Mach-E vehicles built on 2-Mar-2023 and through 16-Mar-2023 may exhibit one or more of the following symptoms: My Trip display in center display screen does not reset to 0 after key cycle, assisted lane change graphics displayed incorrectly, MyKey creation fails on first attempt, hands on icon displayed during hands-free assisted lane change maneuver, excessive 12 volt battery drain. This may be due to the software calibration in the instrument panel cluster (IPC). To correct this condition, update the IPC software using the Ford Diagnostic and Repair Software (FDRS). For claiming, use part number 10849 and the applicable labor operations of Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10237965 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E and 2022-2023 E-Transit vehicles may exhibit an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTC) P0ADA, P0ADE, P0AA1, and/or P0AA4 stored in the battery energy control module (BECM) after high voltage battery junction box (HVBJB) replacement. Vehicle may also exhibit reduced powertrain performance and/or a Stop Safely Now message displayed in the instrument panel cluster (IPC) and/or High-Voltage Battery Warning message in the FordPass application. This may be due to the BECM software. To correct the condition, download and run the BECM - Reset Diagnostic Trouble Code (DTC) Occurrence Counter application in Ford Diagnosis and Repair System (FDRS). If the concern persists, refer to Workshop Manual (WSM), Section 414-03A for normal diagnostics. Some 2021-2023 Mustang Mach-E and 2022-2023 E-Transit vehicles may exhibit an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTC) P0ADA, P0ADE, P0AA1, and/or P0AA4 stored in the battery energy control module (BECM) after high voltage battery junction box (HVBJB) replacement. Vehicle may also exhibit reduced powertrain performance and/or a Stop Safely Now message displayed in the instrument panel cluster (IPC) and/or High-Voltage Battery Warning message in the FordPass application. This may be due to the BECM software. To correct the condition, download and run the BECM - Reset Diagnostic Trouble Code (DTC) Occurrence Counter application in Ford Diagnosis and Repair System (FDRS). If the concern persists, refer to Workshop Manual (WSM), Section 414-03A for normal diagnostics |
| 10237979 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles built on or before 21-Apr-2023 may exhibit a false alarm activation and/or warning message in the FordPass application when the doors are locked. This may be due to the software in the door latch control module E (DCME), door latch control module F (DCMF), door latch control module G (DCMG) and/or door latch control module H (DCMH). To correct the condition, download and run the door control module software update application for each module one at a time using the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 58219A65 and applicable labor times in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10238725 | 2023 | Priority Update 23-PU0314-DCM-LAT for 2023 Mach E vehicles is now available. Quality Improvements include: - Robustness action for commanded door release. |
| 10238892 | 2021,2022,2023 | Certain 2021-2023 Model Year Mustang Mach-E Door Control Module Update Some of the affected vehicles may exhibit a false alarm activation and/or a warning message in the FordPass application when the doors are locked |
| 10239098 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E/F-150, 2022-2023 Expedition/Navigator and 2023 Corsair vehicles may exhibit a Driver Monitoring Camera Blocked message and/or DTCs B115E:97, B15E1:97 and/or B15E2:97 stored in the driver status monitor camera module (CMR). These DTCs should be disregarded unless it is a DTC with a status byte 8F. Other status bytes should be disregarded as they may be caused by a camera obstruction such as driver position, aftermarket devices or dust on the camera. To clear the DTCs, remove anything obstructing the view of the camera and light emitting diodes (LEDs), place the steering wheel in the center position and close the driver door. Connect Ford Diagnosis and Repair System (FDRS) and clear the DTCs. Turn the ignition off and wait 10 seconds. Turn the ignition on and wait 1 minute. Perform the CMR self-test and reevaluate if DTCs persist. |
| 10239477 | 2021,2022,2023 | Some 2021-2023 Ford and Lincoln vehicles may exhibit a condition where the high voltage battery stops charging when connected to level 1 or level 2 chargers with an illuminated malfunction indicator lamp (MIL) and diagnostic trouble code (DTC) P2C94 stored in the secondary on-board diagnostic control module A (SOBDM). To restore charging capability, disconnect the off-board charging station charge handle from the vehicle charge port and reconnect. This condition does not affect vehicle durability and no additional diagnosis or service is required for this condition at this time. Inform customers that they can continue to drive the vehicle and engineering is currently working on a solution for this condition that is expected in August 2023. Replacement of the SOBDM will not resolve this condition. Monitor OASIS for additional information. |
| 10240453 | 2023 | Priority Update 23-PU0110-RAD-PS for 2021 - 2023 Mach E vehicles is now available. Quality Improvements include: Keep Customer Programmed Station Presets during OTA updates. Enable the AM radio configuration on ACM and SYNC. |
| 10240454 | 2023 | Software Update 5 P1 for 2021- 2023 MACH E vehicles is now available. Quality improvements include: On Demand Preconditioning (EV Charge Programming Enhancement). BlueCruise removal of map expiration. |
| 10240455 | 2023 | Software Update 4 P3 for 2023 MACH E vehicles is now available. Quality improvements include: New thermal detection algorithm added for increased component protection. Software compensation and cell calibrations for the low range current sensor chip shortage. Charge Settings Not Storing Consistently Over Key cycle. DTE algorithm improvement to reset learned efficiency after charge event. For vehicles that didn't receive Recall 22S41 & 22S29, will receive in this update. |
| 10240743 | 2021,2022,2023 | The Service Awareness Newsletter is an informal communication that contains information that may not be presently available in a TSB, SSM, GSB, or other electronic communication. This article includes information on warranty, technical service tips and other service information. |
| 10241528 | 2021,2022,2023 | Some 2021-2022 Mustang Mach-E vehicles built on or before 17-Mar-2023 may exhibit an illuminated malfunction indicator lamp (MIL) and/or powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTCs) P0563, P0ADA, P0ADE, P0AA1, P0AA4, P0AA5, P0AA2, P0D10, P0D0F, and/or P0C78 stored in battery energy control module (BECM). It may also have a low/discharged 12V battery and/or display a Stop Safely Now message in the instrument panel cluster (IPC). This may be due to the high voltage battery junction box (HVBJB). To correct the condition, follow the Service Procedure to replace the HVBJB and reprogram the BECM. |
| 10241595 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit an exterior charge status indicator blinking red with diagnostic trouble code (DTC) P0E5F stored in the secondary on-board diagnostic control module A (SOBDM) and the high voltage battery cannot be charged using a 48-amp AC level 2 charger. The vehicle may also exhibit in the next key cycle a Service Soon message in the instrument panel cluster (IPC) and a FordPass warning message. This may be due to an excessive charge port temperature. The concern may not be present when using a 32-amp or lower AC level 2 charger. To correct this condition, remove and replace the charge port. Refer to Workshop Manual (WSM) Section, 414-03B. For claiming, use causal part 14A303 and applicable labor times in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10241600 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E and 2022-2023 E-Transit vehicles may exhibit an inability to clear diagnostic trouble codes (DTCs) P0ADA, P0ADE, P0AA1, and/or P0AA4 stored in the battery energy control module (BECM) after high voltage battery junction box (HVBJB) replacement. To correct the condition, download and run the BECM - Reset Diagnostic Trouble Code (DTC) Occurrence Counter application in Ford Diagnosis and Repair System (FDRS). If the concern persists, refer to Workshop Manual (WSM), Section 414-03A for normal diagnostics. |
| 10241627 | 2021,2022,2023 | In various 2017-2023 Ford and Lincoln vehicles, customers may receive a message in the FordPass or LincolnWay App stating Feature Unavailable. Since this is a fleet vehicle, it cannot access the (SYNC Connect) FordPass or LincolnWay app through the TCU Embedded Modem. If this message appears, the vehicle may be equipped with a fleet telematics module. Replacement of the TCU or TCU related repairs will not prevent this message from appearing. Refer the customer to in app FordPass Guides or LincolnWay Concierge Teams to aid with fleet telematics removal. Open app, select Account > Help > CHAT or CALL option. |
| 10243442 | 2023 | "Software Update SU5 P3 for 2023 Mach E is now available. Quality improvements include: - Adds a ""some display features may be temporarily unavailable"" message to the SYNC screen when a SYNC update is installing. - Improved ""Ask on Exit"" pop- up functionality - Selectable Drive Modes - prevent default to normal mode due to loss of communication with SYNC - Improved charge status indication feedback while plugged in. - Minor changes in appearance for 15"" screen. - BlueCruise removal of map expiration." |
| 10243443 | 2021,2022,2023 | "Software Update SU6 P1 for 2021 - 2023 Mach E is now available. Quality improvements include: -Improved ""Ask on Exit"" pop- up functionality '- Adds a ""some display features may be temporarily unavailable"" message to the SYNC screen when a SYNC update is installing. - Selectable Drive Modes - prevent default to normal mode due to loss of communication with SYNC - Improved Profiles (Enhanced Memory) - prevent getting stuck in GUEST. - Improved feedback of vehicle charging behavior when plugging-in. |
| 10243479 | 2021,2022,2023 | Some 2021-2023 Ford and Lincoln vehicles may exhibit DTCs U2100 and/or U3002 stored in the cruise control module (CCM), side obstacle detection control module LH (SODL), side obstacle detection control module RH (SODR), side obstacle detection control module C (SODCMC) and/or side obstacle detection control module D (SODCMD) after a module replacement. DTC U2100 may set when the module has not been properly configured after replacement. DTC U3002 may set when the module has been configured with the incorrect VIN. To correct this condition, verify that the module storing the DTC has been installed following the applicable Workshop Manual (WSM) Removal and Installation procedure. If the DTC is still stored, download and run the Vehicle Identification Number (VIN) Write application found under Toolbox, Multi-Module tab in the Ford Diagnosis and Repair System (FDRS). |
| 10244693 | 2021,2022,2023 | Customer Satisfaction Program 23B50 Certain 2021-2023 Model Year Mustang Mach-E, 2022-2023 Model Year E-Transit, and 2023 F-150 Lightning Vehicles - Charge Cord Stuck Reprogram Battery Charge Control Module |
| 10244695 | 2022,2023 | Harvest Program 23H05 Certain 2022 Model Year Navigator and 2022-2023 Model Year Mach-E, F150 Lightning, F150, Expedition and Bronco - Instrument Cluster Odometer Inspection |
| 10244796 | 2021,2022,2023 | This article supersedes TSB 22-2496 to update the Title and production clean date. Some 2021-2023 Mustang Mach-E built on or before 15-Sep-2023 and 2022-2023 E-Transit vehicles may experience an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTC) P1A3C, U3000:16, U3000:64, U3000:04 and/or U3000:45 in the off-board charging controller (OBCC) module and the high voltage (HV) battery will not charge using a level 3 direct current (DC) fast charging station/electrical vehicle supply equipment (EVSE). This may be due to OBCC software. To correct the condition, follow the Service Procedure to reprogram the OBCC. |
| 10244816 | 2023 | Software Update SU6 PU0630-RGT-PLO for 2023 MY Mach E is now available. Quality Improvments include: - Robustness action to allow the liftgate to fully open using the exterior button when vehicle is locked. |
| 10244817 | 2023 | Software Update 23- PU0722-DC-CHG3 for 2023 MY Mach E is now available.Quality Improvments include: - Improved DC Fast Charging performance. |
| 10244820 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may experience an exterior charge status indicator not illuminating the blue charging segments after an over the air (OTA) update. Confirm if the Charge Port Light toggle button is not present in the center display screen by selecting Vehicle Icon Controls Access Charge Port Light toggle button, as this button has been removed after OTA update. Replacing the charge port and/or the battery charger control module (BCCM) is not recommended. This condition does not affect charge behavior and no additional diagnosis or service is required for this condition at this time. Inform customers that they can continue to drive the vehicle and engineering is currently working on a solution for this condition that is expected in November 2023. Monitor OASIS for additional information. |
| 10245188 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E, 2022-2023 F-150 Lightning/e-Transit vehicles may exhibit a concern where the vehicle is unable to achieve 100 percent state of charge immediately after high voltage (HV) battery module balancing and replacement. This may be due to the battery energy control module (BECM) adjusting the cell balance (conditioning) of the battery module and should be corrected within 22 days. If the vehicle otherwise functions as designed with no related diagnostic trouble codes (DTC) setting, this concern will be corrected automatically with no further actions required by the technician. |
| 10245416 | 2021,2022,2023 | This article supersedes TSB 23-2257 to update the Parts List. Some 2021-2023 Mustang Mach-E vehicles built on or before 17-Mar-2023 may exhibit an illuminated malfunction indicator lamp (MIL) and/or powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTCs) P0563, P0ADA, P0ADE, P0AA1, P0AA4, P0AA5, P0AA2, P0D10, P0D0F, and/or P0C78 stored in battery energy control module (BECM). It may also have a low/discharged 12V battery and/or display a Stop Safely Now message in the instrument panel cluster (IPC). This may be due to the high voltage battery junction box (HVBJB). To correct the condition, follow the Service Procedure to replace the HVBJB and reprogram the BECM. |
| 10246136 | 2021,2022,2023 | This article supersedes TSB 21-2307 to update the Service Procedure. Some 2021-2023 Mustang Mach-E vehicles built on or before 29-Sep-2023 may experience a water leak into the liftgate. This may be due to water intruding past the seals on the liftgate mounted rear lamp assemblies. To correct the condition, follow the Service Procedure to seal the lamp cavities. |
| 10246348 | 2021,2022,2023 | Software Update SU6 P3 for 2021-2023 MACH E vehicles is now available. Quality Improvements include: - Enable electric return of hood latch release actuator - Corrects erroneous "frunk service required" warning post OTA. - Corrects alarm going off during an OTA download . - improved interior windsheld fogging and heater performance when driving in freezing temperatures - Improved Cold DC Fast Charging and heat sharing/smart heating. - Removal of cause of chime related DTC set against AHU. - Hands-Free to BlueCruise text update. - Adds 3 chimes for Over Speeding situation. - Adds chime for speed limit change. - Adds text box "Hold for Speed Warning OFF" - Introduces a more aggressive series of hood ajar warnings/chimes that trigger at lower speed than the current implementation - The customer is instructed to exit the vehicle when a battery hazard is detected. - IPC software addressing traction control toggle, BLIS and ISA presonaliztion, MyTrip distance reset, Low Tire pressure incorrect reading, and PWM buzz noise elimination. - Provides Yield and No Entry graphic display for Traffic Sign recognition. - Removes Tollbooth Mode - Adds a "some display features may be temporarily unavailable" message to the SYNC screen when a SYNC update is installing. - Profiles (Enhanced Memory) will not be stuck as Guest - Improved "Ask on Exit" pop- up functionality - Selectable Drive Modes - prevent default to normal mode due to loss of communication with SYNC - Improved charge status indication feedback while plugged in. |
| 10246349 | 2023 | Software Update 23-PU0314-DCM-LAT for 2023 MACH E vehicles is now available. Quality Improvements include: - Software update to prevent electronic door unlatching when the vehicle speed is greater than 3 kph. |
| 10246350 | 2023 | Software Update 23-PU0725-CLM-FX for 2023 MACH E vehicles is now available. Quality Improvements include: -Increase the HWS (Heated Windshield) on time when manually requested by the customer to improve defrosting performance |
| 10246351 | 2023 | Software Update 23-PU1103-NAT-VCE for 2022 - 2023 MACH E vehicles is now available. Quality Improvements include: - Adds a "some display features may be temporarily unavailable" message to the SYNC screen when a SYNC update is installing. - Profiles (Enhanced Memory) will not be stuck as Guest - Improved "Ask on Exit" pop- up functionality - Selectable Drive Modes - prevent default to normal mode due to loss of communication with SYNC - Improved charge status indication feedback while plugged in. - Digital owner Manual addition (2023MY Only) |
| 10246352 | 2023 | Software Update 23-PU0907-RAD-ON for 2023 MACH E vehicles is now available. Quality Improvements include: - The customer will no longer lose their radio presets when the vehicle receives OTA updates. - Turns on AM Radio access |
| 10247169 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E, 2022-2023 E-Transit/F-150 Lightning vehicles may have diagnostic trouble code (DTC) P1A3C stored in the off-board charger controller module (OBCC). The P1A3C is commonly set due to an interruption of the direct current (DC) fast charging process and should be disregarded. All other DTCs stored in the OBCC are to be addressed using applicable publications and/or normal diagnostics found in Workshop Manual, Section 414-03B. |
| 10247526 | 2021,2022,2023 | Various 2021-2024 Ford and Lincoln vehicles equipped with the rear camera on demand feature may exhibit a Please Check Surroundings For Safety or Full View Not Available message when the rear camera button is pressed and the vehicle is not in reverse. Inform customers this condition is considered normal operation and does not affect vehicle durability because the full rear view camera image can only be shown when the vehicle is in reverse. No additional diagnosis or service is required for this condition. |
| 10248265 | 2022,2023 | Software Update SU6 P4 for 2022- 2023 MY Mach E vehicles is now available. Quality improvements include: - Adds robustness to the Driver State Monitoring system and increases availability of BlueCruise - 22 MY Reduces false eyes-off warnings |
| 10248267 | 2023 | Software Update 23-PU1024-MCP-FX for 2023 MY Mach E vehicles is now available. Quality improvements include: - Improvements to State of Charge accuracy during AC charging - Robustness actions for DC Fast Charge, charging,and diagnostics - Improvements to On Demand Preconditioning. - The customer is instructed to exit the vehicle when a battery hazard is detected. - PWM buzz noise elimination - Improves HV Battery Charging experience. - Corrects configuration for VINs built with incorrect ABS cal. |
| 10248271 | 2021,2022,2023 | Software Update SU7 P1 for 2021- 2023 MY Mach E vehicles is now available. Quality improvements include: - Reduces erroneous BLIS warning 21 MY: - Increases availability of BlueCruise. Ignition reset will not be necessary to reengage BlueCriuse. - Reduces false eyes-off warnings - Improved OTA success rate 21-22 MY: - Improved Reverse Brake assist availability - Customer is instructed to exit the vehicle when a battery hazard is detected - Enables the e-release feature on the front trunk. |
| 10248353 | 2021,2022,2023 | Some 2021-2023 Mach-E vehicles built on or before 29-May-2023 may experience an alarm activation even after the motion sensor function has been disabled through the pop-up menu at ignition off. This may be due to the software in the SYNC module (APIM). To correct the condition, follow the Service Procedure steps to reprogram the APIM. NOTE: The APIM software update that addresses the symptom listed in this bulletin may have been sent via Ford Power-Up software updates delivered over-the-air (OTA) to connected vehicles that have automatic updates enabled through the center display screen. Enter the vehicle identification number (VIN) in Professional Technician System (PTS) and check the OTA Dashboard under the Connected Vehicle tab for OTA update history. If an update to the APIM has successfully completed recently and the customer is reporting the symptoms are no longer present, this article may not apply. |
| 10248355 | 2021,2022,2023 | This article supersedes TSB 23-2326 to remove a DTC from the Issue and Action. Some 2021-2023 Mustang Mach-E built on or before 15-Sep-2023 and 2022-2023 E-Transit vehicles may experience an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTC) U3000:16, U3000:64, U3000:04 and/or U3000:45 in the off-board charging controller (OBCC) module and the high voltage (HV) battery will not charge using a level 3 direct current (DC) fast charging station/electrical vehicle supply equipment (EVSE). This may be due to the software in the OBCC. To correct the condition, follow the Service Procedure to reprogram the OBCC. |
| 10248358 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a condition where the high voltage battery stops charging when connected to level 1 or level 2 chargers with an illuminated malfunction indicator lamp (MIL) and diagnostic trouble code (DTC) P2C94 stored in the secondary on-board diagnostic control module A (SOBDM). This may be due to the software in the SOBDM. To correct this condition, follow the Service Procedure to reprogram the powertrain control module (PCM). |
| 10249488 | 2021,2022,2023 | Certain 2021-2023 Model Year Mustang Mach-E and 2022-2023 Transit Battery Electric Vehicle (BEV) High Voltage Battery Module Replacement |
| 10249754 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles built on or before 04-Dec-2023 may exhibit a wind noise from the exterior mirrors/A-pillar area when driving at or above 40 mph (64 km/h). This may be due to poor sealing of the lower mirror foam and the glass top run foam. |
| 10249757 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles built on or before 24-Jun-2023 may exhibit a condition where the high voltage battery slow charging or does not charge while using a level 1 or level 2 electric vehicle supply equipment (EVSE) after an over the air (OTA) update. This may be due to the software in the secondary on-board diagnostic control module A (SOBDM) |
| 10249758 | 2021,2022,2023 | Some 2021-2023 Mach-E vehicles may exhibit the drive mode default to normal mode while driving and Drive Mode Not Available message displays in the center display screen with or without diagnostic trouble code (DTC) U0253 stored in the anti-lock brake system module (ABS). This may be due to the software in the SYNC module (APIM). The APIM software update that addresses the symptom listed in this bulletin may have been sent via Ford Power-Up software updates delivered over-the-air (OTA) to connected vehicles that have automatic updates enabled through the center display screen. Enter the vehicle identification number (VIN) in Professional Technician System (PTS) and check the OTA Dashboard under the Connected Vehicle tab for OTA update history. If an update to the APIM has successfully completed recently and the customer is reporting the symptoms are no longer present, this article may not apply. |
| 10249770 | 2022,2023 | Some 2022-2023 Mustang Mach-E vehicles which recently received an OTA update may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble codes (DTCs) U2018:51 stored in the camera module - rear (CMR) and U0565:86 stored in the image processing module A (IPMA). This may be due to the software level of the CMR. Inform customers that engineering is currently working on a solution for this condition and will be released via Ford Power-Up software updates delivered over-the-air (OTA) expected in March 2024. The software will update automatically if vehicle connectivity is enabled on the vehicle's settings. Schedule a service visit for customers who have disabled vehicle connectivity or who report that they did not receive the update in March 2024. Monitor OASIS for additional information. |
| 10249789 | 2021,2022,2023 | Some 2023 Escape vehicles equipped with a head up display (HUD) built on or before 16-Oct-2023 may exhibit a condition where the speed limit sign indicator is not displayed in the HUD. This may be due to the software installed in the HUD module. |
| 10249825 | 2021,2022,2023 | Software Update FPU 23-PU1113-UNX-DC for 2021-2023 MY Mach E vehicles is now available. Quality Improvements include: - Restores TCU module DID vehicle specific configuration which were set to default values in previous OTA update. |
| 10250834 | 2021,2022,2023,2024 | Some 2021-2024 Mustang Mach-E, 2022-2024 E-Transit/F-150 Lightning vehicles may have diagnostic trouble code (DTC) P1A3C stored in the off-board charger controller module (OBCC). The P1A3C is commonly set due to an interruption of the direct current (DC) fast charging process and should be disregarded. All other DTCs stored in the OBCC are to be addressed using applicable publications and/or normal diagnostics found in Workshop Manual, Section 414-03B. |
| 10251458 | 2021,2022,2023 | This article supersedes TSB 23-2399 to update the vehicle lines affected. 2021-2023 Mustang Mach-E and 2023 e-Transit vehicles may exhibit a condition where the high voltage battery stops charging when connected to level 1 or level 2 chargers with an illuminated malfunction indicator lamp (MIL) and diagnostic trouble code (DTC) P2C94 stored in the secondary on-board diagnostic control module A (SOBDM). This may be due to the software in the SOBDM. To correct this condition, follow the Service Procedure to reprogram the powertrain control module (PCM). |
| 10251476 | 2022,2023 | Software Update FPU 24-PU0105-CMR-FX for 2022-2023 MY Mach E vehicles is now available. Quality Improvements include - Adds robustness to the Driver State Monitoring system and increases availability of BlueCruise - 22MY Reduces false eyes-off warnings |
| 10251494 | 2023,2024 | Software Update FPU 24-PU0121-FTDI-FX for 2023-2024 MY Mach E vehicles is now available. Quality Improvements include - FordPass will remember last known profile. - Allow customers to exit during OTA update. - Improves BCM response to de-inhibit request when OTA is complete. - Allows vehicle to return to sleep after detecting CAN traffic, for reduced battery drain. - Perimeter alarm duty cycle for horn and light aligned with non -US market requirements. (ECE-116) |
| 10251956 | 2022,2023,2024 | Some 2022-2024 various Ford/Lincoln vehicles equipped with SYNC 4 may experience concern where customers are receiving an error message when trying to enroll in connected services. This may be due to the gateway module (GWM) software. To correct the concern, download and run the Transport and Factory Mode Deactivation app: under HS1 modules select BCM > Transport and Factory Mode > Download > Run. When the pop-up message appears for Change Vehicle Mode - Transport/Factory/Normal Mode, press OK. This will proceed to the Transport and Factory Mode Deactivation screen, select Unlock Vehicle Connectivity Settings (21 MY + Vehicles). A pop-up message appears noting Vehicle Is Now In Normal Mode, select OK. This will return to the Transport and Factory Mode Deactivation screen, select Exit. A final pop-up notification stating that the application is finished, select OK. For claiming, use causal part 14G490 and applicable labor operations in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 10252416 | 2021,2022,2023 | Harvest Program 23H06 Certain 2021-2023 Model Year Mustang Mach-E and 2022-2023 Transit Battery Electric Vehicle (BEV) High Voltage Battery Module Replacement Owner letter added. Other documents submitted 02/01/24 |
| 10252527 | 2021,2022,2023 | 2021-2023 Mach-E vehicles may exhibit the drive mode default to normal mode while driving and <Drive Mode Not Available> message displays in the center display screen with or without Diagnostic Trouble Code (DTC) U0253 stored in the ABS module. This may be due to the software in the APIM. |
| 10252532 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a wind noise from the exterior mirror/A-pillar area when driving at or above 64 km/h (40 mph). This may be due to poor sealing of the lower mirror foam and the glass top run foam.. Some 2021-2023 Mustang Mach-E vehicles may exhibit a wind noise from the exterior mirror/A-pillar area when driving at or above 64 km/h (40 mph). This may be due to poor sealing of the lower mirror foam and the glass top run foam.. |
| 10252543 | 2022,2023 | Some 2022-2023 Mustang Mach-E vehicles which recently received a Ford Power-Up software updates delivered over-the-air (OTA) may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble codes (DTCs) U2018:51 stored in the camera module - rear (CMR) and U0565:86 stored in the image processing module A (IPMA). This may be due to the software level of the CMR. |
| 10252622 | 2022,2023 | Some 2022-2023 Mustang Mach-E vehicles which recently received an OTA update may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble codes (DTCs) U2018:51 stored in the camera module - rear (CMR) and U0565:86 stored in the image processing module A (IPMA). This may be due to the software level of the CMR. Inform customers that engineering is currently working on a solution for this condition and will be released via Ford Power-Up software updates delivered over-the-air (OTA) expected in mid-late March 2024. The software will update automatically if vehicle connectivity is enabled on the vehicle's settings. Schedule a service visit for customers who have disabled vehicle connectivity or who report that they did not receive the update in March 2024. Monitor OASIS for additional information. |
| 10252665 | 2022,2023 | Some 2022-2023 Mustang Mach-E vehicles which recently received a software update delivered over-the-air (OTA) may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble codes (DTCs) U2018:51 stored in the camera module - rear (CMR) and U0565:86 stored in the image processing module A (IPMA). This may be due to the software level of the CMR. To correct the condition, follow the Service Procedure to reprogram the CMR module using the latest software level of the Ford Diagnosis and Repair System (FDRS). |
| 10252668 | 2023 | Some 2023 Mustang Mach-E vehicles built on 29-May-2023 and through 21-Nov-2023 may exhibit an exterior blue charge status indicator segments flashing and high voltage battery continues to charge after preset charge target percentage has been met while using level 1 or level 2 charger. This may be due to the software in the secondary on-board diagnostic control module A (SOBDM). |
| 10253552 | 2021,2022,2023,2024 | Various vehicles have had pinpoint tests, guided routines and the Warranty and Policy Manual recentlyupdated for diagnostics and repairs on SYNC generation 3 and later applications. When performingdiagnostics and repairs on SYNC Gen 3 or later, select the diagnostics tab and search for related symptoms,DTCs and keywords. The search results will be shown in the search results pane. Read and follow allTechnical Service Bulletins (TSB), Special Service Message (SSM)s or General Service Bulletin (GSB) first if abulletin specifically addresses the vehicle concern. If there are no messages, run the appropriate diagnosticpinpoint test found in the Workshop Manual (WSM). Follow the steps in the pinpoint test. Make sure to note thetitle of the guided routine, using the correct one for the vehicle's symptom or diagnostic trouble code (DTC) iscritical. Depending on the outcome of the pinpoint test, a repair validation code (RVC) may be generated eitherin the pinpoint test or Guided Routine. If the vehicle concern still exists after following the pinpoint tests orguided routine, then a manual RVC can be generated using the RVC Assist Form. A manual RVC can only begenerated once the above process has been followed. |
| 10254131 | 2023,2024 | Some 2023-2024 Mustang Mach-E/Corsair and 2024 Mustang vehicles may exhibit an audio control module (ACM) programming failure with a message displayed in the Ford Diagnosis and Repair System (FDRS) scan tool indicating Procedure Unsuccessful-Flash Software Failed To Flash. This may be due to the ACM programming routine. To correct this condition, download and click the refresh icon located next to the run icon to update the ACM - Programmable Module Installation (PMI) app. For claiming, use causal part 18C869 and applicable labor operations in Section 11 of the Service Labor Time Standards (SLTS) Manual. |
| 10254147 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a "1 Pedal Drive Fault - Press Brake Pedal To Reduce Speed" warning message displayed in the instrument panel cluster (IPC) after a recent powertrain software update was received. A diagnostic trouble code (DTC) P0C2F:92 may also be stored in the secondary on-board diagnostic module-C (SOBDMC). This concern may also be present when One Pedal Drive mode is enabled. This condition does not affect vehicle durability and no additional diagnosis or service is required for this condition at this time. Inform customers that they can continue to drive the vehicle and engineering is currently working on a solution for this condition that is expected by early May 2024. Replacement or reprogramming of SOBDMC and/or the PCM will not resolve this condition. Module reprogramming in the Ford Diagnosis and Repair System (FDRS) has been temporarily suspended for powertrain modules. Monitor Professional Technician System (PTS), OASIS, and FSA landing pages for additional information and schedule service appointments for customers once the repair becomes available. |
| 10254320 | 2021,2022,2023 | Quality improvements include: -22, 23 and 21 MYs: Fix the infrequent random audio noises and improve the audio quality of the vehicle. -23.5 MY may lose audio on rear left woofer/tweeter (Channel 1) |
| 10254325 | 2023,2024 | Quality improvements include: Numerous minor quality fixes in ECG RC9 which are not customer facing. Improves OTA deployment reduce FTDI risk. |
| 10254329 | 2021,2022,2023 | Quality Improvements include: - Allows the user to open any vehicle door if the phone is within 6m of the vehicle. - Improves the success rate for the Passive Entry feature. - Allows persons to enter the vehicle independent of which side the phone is located. |
| 11000183 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles built on or before 21-Apr-2023 may exhibit a false alarm activation and/or warning message in the FordPass application when the doors are locked. This may be due to the software in the door latch control module E (DCME), door latch control module F (DCMF), door latch control module G (DCMG) and/or door latch control module H (DCMH). To correct the condition, download and run the door control module software update application for each module one at a time using the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 58219A65 and applicable labor times in Section 10 of the Service Labor Time Standards (SLTS) Manual. |
| 11000742 | 2023 | This article supersedes TSB 24-2094 to update the production fix date and causal part. Some 2023 Mustang Mach-E vehicles built on 26-Jun-2023 and through 21-Nov-2023 may exhibit an exterior blue charge status indicator segments flashing and high voltage battery continues to charge after preset charge target percentage has been met while using level 1 or level 2 charger. This may be due to the software in the secondary on-board diagnostic control module C (SOBDMC). To correct the condition, follow the Service Procedure to reprogram the SOBDMC. |
| 11001112 | 2021,2022,2023,2024 | Some vehicles equipped with SYNC4 may exhibit one or more of the following symptoms after all currently available accessory protocol interface module (APIM) software updates have been performed. - General system performance, stability, and intermittent system reboots. - Intermittent Wireless CarPlay or Android Auto function. - Phone related concerns with intermittent No Audio or Static. - Navigation/global positioning system (GPS) related concerns through CarPlay and Android Auto. - Alexa function consistency and stability. These symptoms may be due to the software in the APIM. Replacing the APIM will not resolve these symptoms for the customer. Before returning the vehicle to the customer, review the procedures within Workshop Manual, Section 415-00 and ensure the latest APIM software is installed. Refer to General Service Bulletin (GSB) 23-7146 for help determining the latest available level of software. IMPORTANT: some module software updates will only display as available on Ford Diagnosis and Repair System (FDRS) after prerequisite modules are updated. This may require the technician to update certain modules multiple times during the service visit, before the latest APIM software is accessible in FDRS. If symptoms continue after latest APIM software has been installed, inform customers that Ford is working on additional software enhancements which are expected to be delivered over-the-air (OTA) by Q4 2024 on F-150, F-150 Lightning, Mustang Mach-E, Mustang, Escape, Corsair, Expedition, Navigator, Bronco, Mustang, and 2023-2024 F-Super Duty. Software will update automatically if vehicle connectivity is enabled in the vehicle's settings. For all other vehicles with SYNC4, schedule a service visit for customers in October 2024, when the updated APIM software is expected to be available to dealers. Monitor OASIS for additional information. |
| 11001150 | 2021,2022,2023 | Certain 2021-2023 Model Year Mach-E Vehicles - Paint Sealant Issues - Door Hems Inspection - Repair |
| 11001647 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles may exhibit a "1 Pedal Drive Fault - Press Brake Pedal To Reduce Speed" warning message displayed in the instrument panel cluster (IPC). The customer may also notice that the 1 Pedal Drive feature has been deactivated. A diagnostic trouble code (DTC) P0C2F:92 may also be stored in the secondary on-board diagnostic module-C (SOBDMC). This concern may also be present when one pedal drive mode is enabled. This may be due to the SOBDMC. To correct the condition, follow the Service Procedure to reprogram the powertrain modules using the latest level of the Ford Diagnosis and Repair System (FDRS). |
| 11003262 | 2023,2024 | Quality Improvments include: - Phone as a Key resolution, not affecting customer vehicles. |
| 11003265 | 2023 | Quality improvements include: - Update to resolve potential KOL/battery drain. |
| 11003273 | 2021,2022,2023,2024 | Quality improvements include: - Reduced ADAS loss of communication events - Adds camera retry strategy robustness action - 21 MY: Removes erroneous ""Reverse Brake Unavailable"" message. |
| 11005308 | 2021,2022,2023,2024 | This article supersedes TSB 24-2002 to update the symptom, production fix date and the service procedure. Some 2021-2024 Mustang Mach-E vehicles built on or before 09-Jul-2024 may exhibit a wind noise from the exterior mirrors/A-pillar area when driving between 25 mph-40 mph (32 km/h-64 Km/h). This may be due to poor sealing of the lower mirror foam and the glass top run foam. To correct this condition, follow the Service Procedure to install new lower inner foam and the glass top run foam. |
| 11005840 | 2023 | Some 2023 Mustang Mach-E/e-Transit vehicles built on or before 09-Dec-2023 may exhibit an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble codes (DTC) P0B3B, P0B40, P0B45, P0B4A, P0B4F, P0B54, P0B59, and/or P0B5E stored in the battery energy control module (BECM). Vehicle may also exhibit a no start condition, inability to charge the battery and/or a "Stop Safely Now" message displayed in the instrument panel cluster (IPC). This may be due to an intermittent condition in the BECM flexible printed circuit cable. |
| 11006045 | 2023 | Certain 2023 Model Year Mustang Mach-E Vehicles 12 Volt (12V) Battery Test and Remote Climate Control Module (RCCM) Reset On the affected vehicles, the Remote Climate Control Module (RCCM) may stay awake after the vehicle is turned off, creating a Key Off Load (KOL). This may cause DTC B1616-04 to set, and a message Electrical System Drain Service Required to appear on the Instrument Panel Cluster (IPC) and may also lead to a discharge of the 12V battery if the vehicle is parked for approximately 10-15 days |
| 11006769 | 2021,2022,2023,2024 | This article supersedes TSB 24-2087 to update the vehicle lines, model years affected, action and service procedure. Some 2021-2024 Mustang Mach-E/F-150, 2022-2024 F-150 Lightning/Expedition/Navigator, 2023-2024 Corsair vehicles may exhibit an inoperative BlueCruise and lane centering with DTCs U2018:51 stored in the camera module - rear (CMR) and U0565:86 stored in the image processing module A (IPMA) without DTC U3000:49 stored in the CMR. This may be due to the software level of the CMR. To correct the condition, follow the Service Procedure to reprogram the CMR module using the latest software level of the Ford Diagnosis and Repair System (FDRS). |
| 11007033 | 2021,2022,2023 | Certain 2021 - 2023 Model Year Mustang Mach-E Vehicles Powertrain Control Module Coordinated Software Update In some of the affected vehicles, the vehicle may disengage the one pedal drive mode at speeds below 15 MPH accompanied by a one pedal drive fault pop-up message displayed in the instrument panel cluster. |
| 11007124 | 2023,2024 | Quality Improvements include: - 23 MY Robustness action to improve Phone as a Key Feature Key functionality post Enhanced Central Gateway (ECG) reset. - 23 MY Minor quality fixes in Enhanced Central Gateway (ECG) Software, not affecting vehicle operation. - Addresses potential unintended lock out of vehicle after OTA update. |
| 11007130 | 2023 | Quality Improvements include: - Addresses Accessory Protocol Interface Module (SYNC) displaying update status as not completed. - Reduction in Key off load battery drain via Enhanced Central Gateway (ECG) controlled reset. - Reduction in Key off load battery drain due to Bluetooth Low Energy Module (BLEM) software - Addresses potential lock out condition post OTA update. |
| 11007138 | 2023 | Quality Improvements include: - Reduction in Key off load battery drain via Enhanced Central Gateway (ECG) controlled reset. |
| 11007977 | 2021,2022,2023,2024 | Some 2020-2024 Explorer/Aviator/Corsair, 2021-2024 F-150/Bronco, 2023-2024 F-Super Duty, and 2024-2025 Nautilus vehicles may experience the overhead console sunglass bin cannot be locked in a closed position. |
| 11008378 | 2023,2024 | In some of the affected vehicles, if an attempt is made to repair a flat tire using the sealant system included in the vehicles tire sealant and inflator kit, the system will not provide sealant or air to inflate and seal the tire. The air-only function will operate as expected. |
| 11008499 | 2023,2024 | "Quality improvements include: -Allows SYNC strategy for Charge Status message to match Cluster strategy. - Top off the Low Voltage battery prior to OTA update. (EV only) - Enables Public Charging App function above 5 MPH. - Hides ""Update Now"" button on HMI when the vehicle battery health is below threshold. - Corrects ""Bluecruise Maps not up to date"" erroneous message. - Improves Key Off Load battery drain due to SYNC. " |
| 11008554 | 2022,2023 | "Quality Improvements include: '- Improved connectivity. - Reduces TCU based Key Off Load battery drain. - Map orientation improvement - Removes false""IP Configuration Failure"" message when wrong WiFi password is entered. - Improves functionality of Stolen Vehicle Services" |
| 11008698 | 2021,2022,2023,2024 | Some 2021-2024 Ford and Lincoln vehicles may exhibit diagnostic trouble codes (DTCs) U2100 and/or U3002 stored in the cruise control module (CCM), side obstacle detection control module LH (SODL), side obstacle detection control module RH (SODR), side obstacle detection control module C (SODCMC) and/or side obstacle detection control module D (SODCMD) after a module replacement. |
| 11008706 | 2021,2022,2023 | An intermittent black screen in the vehicle center display screen with a "Camera Is Unavailable. Please Contact Your Dealership." message in the instrument panel cluster (IPC) when the vehicle is in reverse and DTC B1578:89 stored in the image processing module A (IPMA) may be present on some of the following Ford and Lincoln vehicles: * 2024 F-150/F-Super Duty built on or before 08-Apr-2024 * 2024 Expedition/Navigator built on or before 07-Mar-2024 * 2024 Corsair built on or before 30-May-2024 * 2021-2024 Mustang Mach-E built on or before 20-May-2024 |
| 11008948 | 2021,2023,2024 | While performing a transmission repair on some 2012-2024 Ford and Lincoln vehicles, a transmission seal kit may be on backorder due to supply chain interruptions. While performing a transmission repair on some 2012-2024 Ford and Lincoln vehicles, a transmission seal kit may be on backorder due to supply chain interruptions. |
| 11009438 | 2021,2022,2023,2024 | Some vehicles equipped with SYNC4 may exhibit one or more of the following symptoms after all currently available accessory protocol interface module (APIM) software updates have been performed. |
| 11010786 | 2022,2023,2024 | Some 2022-2024 Mustang Mach-E vehicles may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble code (DTC) U3000:49 stored in the camera module rear (CMR). |
| 11010851 | 2021,2022,2023,2024 | For 2022-2024 e-Transit vehicles equipped with the standard range battery with engine code "ENC0" and 2021-2024 Mustang Mach-E vehicles when attempting to charge/balance high voltage battery modules (arrays) from remanufactured array kits, the Midtronics xMB tool will not recognize the remanufactured part number. |
| 11011014 | 2021,2022,2023 | In the affected vehicles, the Battery Charger Control Module (BCCM) software does not have a transfer function that predicts the charging port pin/terminal temperature. Some customers indicate that their battery may not fully charge and/or the charge cord may become stuck in your vehicle. Customers may also experience a burning smell or melting of the charge port pins. |
| 11012155 | 2023,2024 | Some 2023-2024 Mustang Mach-E vehicles built on or before 06-Dec-2024 may exhibit a condition where the high voltage battery does not charge while using a DC fast charger level 3 and a charge error message displayed on the charger with DTC U049C stored in the BECM. |
| 11013562 | 2021,2022,2023 | Some 2021-2024 Mustang Mach-E and 2023-2025 Escape/Corsair vehicles may exhibit only continuous memory diagnostic trouble code (CMDTC) U2016:47 stored in the power steering control module (PSCM) after a self test is performed with Ford Diagnosis and Repair System (FDRS) scan tool. |
| 11014410 | 2021,2022,2023,2024 | Some of the vehicles listed in the Model statement above may exhibit an unintended deceleration without a vehicle in front when using adaptive cruise control (ACC) or BlueCruise. This may be due to the front bumper affecting both corner radar sensor signals. |
| 11014831 | 2021,2022,2023,2024 | Some of the vehicles listed in the Model statement above may exhibit at least one of the following conditions: * General system performance/stability/intermittent system reboot * Intermittent wireless Apple CarPlay or Android Auto function * Phone related concerns with intermittent no audio or static * Navigation/global positioning system (GPS) related concerns through Apple CarPlay and Android Auto * Alexa function consistency and stability |
| 11014839 | 2021,2022,2023 | Some of the vehicles listed in the Model statement above may exhibit a 12-volt battery drain. |
| 11015516 | 2021,2022,2023 | Some 2021-2024 Mustang Mach-E and 2023-2025 Escape/Corsair vehicles may exhibit only continuous memory diagnostic trouble code (CMDTC) U2016:47 stored in the power steering control module (PSCM) after a self test is performed with Ford Diagnosis and Repair System (FDRS) scan tool. |
| 11015524 | 2022,2023 | Some 2022-2023 Mustang Mach-E vehicles may exhibit the condition where the speedometer stays at 1 mph (1 km/h) when the vehicle is stopped and/or lags during decelaration and aceleration. |
| 11016076 | 2021,2022,2023,2024 | This article supersedes TSB 24-2251 to update the labor times associated with the Service Procedure from M-time to AP-time. |
| 11016078 | 2021,2022,2023,2024 | This article supersedes TSB 25-2049 to update the labor time description. |
| 11016089 | 2021,2022,2023,2024,2025 | Some 2021-2025 Ford vehicles may exhibit a condition where heated/cooled seats, heated steering wheel and/or front/rear defrost features will not turn on after a remote start is performed through the FordPass application or the key fob. |
| 11016915 | 2021,2022,2023,2024 | Some 2021-2025 Ford and Lincoln vehicles may exhibit diagnostic trouble code (DTCs) U2100 and/or U3002 stored in the cruise control module (CCM), side obstacle detection control module LH (SODL), side obstacle detection control module RH (SODR), side obstacle detection control module C (SODCMC) and/or side obstacle detection control module D (SODCMD) after a module replacement. |
| 11017056 | 2022,2023,2024 | Some of the vehicles listed in the Model statement above equipped with extended range battery may exhibit a powertrain malfunction (wrench) indicator with diagnostic trouble code (DTC) P0ADA stored in the battery energy control module (BECM). This may be due to the BECM software level. |
| 11017058 | 2023,2024 | Some of the vehicles listed in the Model statement above may experience exterior paint blistering in at least one of the following areas: * Front and rear door skin panel(s) and door jamb area(s) * Rear quarter panel(s) and jamb area(s) * B-pillar outer panel(s) and jamb area(s) * Roof panel and jamb area(s) * Rocker panel(s) and jamb area(s) This may be due to the factory painting process. |
| 11017336 | 2021,2022,2023 | This article supersedes TSB 23-2155 to update the Service Procedure and change labor operation from actual time to fixed time. Some of the vehicles listed in the Model statement above may exhibit diagnostic trouble codes (DTCs) C1001:31, U3000:89, and/or U3000:49 stored in the image processing module A (IPMA) and at least one of the following conditions: - "Front Camera Fault Service Required" message - Pre-collision Assist inoperative - Adaptive cruise control inoperative - Front windshield camera alignment routine fails to complete This may be due to a connection issue between the IPMA Camera and the IPMA. |
| 11017813 | 2021,2022,2023,2024 | Customer Satisfaction Program 24N08 - Supplement #1 Certain 2021-2024 Bronco Sport, Escape, Mach-E, and 2022-2024 Maverick Vehicles Drivers Side Seat Buckle Replacement |
| 11018321 | 2023,2024 | This article supersedes TSB 25-2149 to update the labor operation allowance. Some of the vehicles listed in the Model statement above may experience exterior paint blistering in at least one of the following areas: * Front and rear door skin panel(s) and door jamb area(s) * Rear quarter panel(s) and jamb area(s) * B-pillar outer panel(s) and jamb area(s) * Roof panel and jamb area(s) * Rocker panel(s) and jamb area(s) This may be due to the factory painting process. |
| 11018618 | 2021,2022,2023 | This bulletin supersedes 24-2187. Reason for update: Add labor operation A and changed MT to AP with a limit. Some of the vehicles listed in the Model statement above may exhibit a "1 Pedal Drive Fault - Press Brake Pedal To Reduce Speed" warning message displayed in the instrument panel cluster (IPC). |
| 11019203 | 2023 | "Quality improvements include: - Brake pedal tuning parameters updated for an improved pedal feel -Calibration update to ensure One Pedal Drive functionality" |
| 11019205 | 2023 | """Quality improvements include: - Brake pedal tuning parameters updated for an improved pedal feel""" |
| 11019208 | 2023,2024 | "Quality improvements include: -Radio reflash to include AM radio option -Addresses a potential SiriusXM false banner showing ""Hardware problem""" |
| 11019419 | 2023 | This article supersedes TSB 24-2141 to update the service procedure and change labor operation from actual time to actual time with a limit. Some of the vehicles listed in the Model statement above may exhibit all of the following conditions: * Charge status indicator (CSI) segments flashing blue * High voltage battery continues to charge after preset charge target percentage has been met while using level 1 or level 2 charger. This may be due to the software in the secondary on-board diagnostic control module C (SOBDMC). |
| 11019702 | 2021,2022,2023 | Some 2021-2025 Ford/ Lincoln vehicles equipped with SYNC4 may not be able to perform an update to the accessory protocol interface module (APIM). This may be due to the software in the APIM. Ford Engineering has de-activated the ability to update these SYNC4 APIM modules as applicable, and the Ford Diagnosis and Repair System (FDRS) will not present an update for the APIM module. Some existing directed repairs may be impacted, check Professional Technician System (PTS) before attempting any specific technical service bulletin (TSB)/special service message (SSM) and check field service action (FSA) landing pages before attempting any FSA repairs. For any vehicle repairs requiring a software update that includes an APIM update in the programming sequence, if the 5-digit product code for the APIM software is equal to or lower than 23187, do not attempt to update affected modules at this time. To determine the 5-digit product code for the APIM software on the vehicle, while the vehicle center display screen is powered up with ignition in run or accessory, go to Settings > General > About SYNC. |
| 11019887 | 2021,2022,2023 | Some of the vehicles listed in the Model statement above may exhibit at least one of the following conditions: *Speedometer stays at 1 mph (1 km/h) when the vehicle is stopped *Speedometer lags during deceleration and acceleration *Car image in the center of the IPC is always displayed *Speedometer is delayed in displaying on bootup *IPC bootup is delayed when attempting to start the vehicle directly from accessory mode *IPC is stuck on the charging/accessory screen when placed in Drive/ready to drive *After vehicle start up, the lane keeping system status telltale briefly displays *Buzz noise from the IPC that changes with the brightness setting This may be due to the software in the IPC. |
| 11019890 | 2021,2022,2023 | This article supersedes TSB 24-2010 to update the Service Procedure and change labor operation from actual to fixed time. Some of the vehicles listed in the Model statement above may exhibit a condition where the high voltage battery charges slowly or does not charge while using a level 1 or level 2 electric vehicle supply equipment (EVSE) after an over the air (OTA) update. This may be due to the software in the secondary on-board diagnostic control module A (SOBDM). |
| 11020122 | 2021,2022,2023 | "Quality improvements include: -Addresses cases where the cluster was stuck on charging screen -Addresses Instrument Panel Cluster delays after doing a quick restart -Customers will be able to turn off the traction control using the toggle" |
| 11020891 | 2022,2023,2024 | Some 2022-2024 Mustang Mach-E vehicles may exhibit an inoperative BlueCruise and lane centering with diagnostic trouble code (DTC) U3000:49 stored in the camera module rear (CMR). This may be due to the software level of the CMR. Inform customers that engineering is currently working on a solution for this condition that is expected in Q3 2025. Monitor Professional Technician System (PTS) for additional information. |
| 11021358 | 2021,2022,2023,2024,2025 | Some 2021-2025 Ford and Lincoln vehicles equipped with SYNC4/Digital Experience may exhibit an unsuccessful telematics control unit module (TCU) software update or software activation during a universal serial bus (USB) update. This may be due to the vehicle connectivity setting being disabled. |
| 11021510 | 2023,2024 | Quality improvements include: -Addresses potential SiriusXM no audio and a false banner showing "Hardware problem" |
| 11021977 | 2021,2022,2023,2024 | Some 2021-2024 F-150 vehicles equipped with a B&O audio system (minor feature code IDBBQ), and various 2021-2024 Ford and Lincoln vehicles equipped with a B&O audio system may exhibit a pop noise and/or static in the speakers at start up that cannot be turned down or off using the audio system controls. To confirm a vehicle is built with a certain minor feature code, review the build information by double-clicking the vehicle identification number (VIN) in the upper left corner on Professional Technician System (PTS). This may be due to software in the digital signal processing (DSP) module. To correct this condition, reprogram the DSP module to the latest software level using the Ford Diagnosis and Repair System (FDRS) scan tool. For claiming, use causal part 18B849 and labor operations 12651D and 12651D4. |
| 11021995 | 2022,2023,2024 | "Quality improvements include: -Addresses a Diagnostic Trouble Code that causes the Driver State Monitoring Camera module to get stuck in bootloader" |
| 11023196 | 2021,2022,2023,2024,2025 | Some of the vehicles listed in the Model statement above may exhibit an inoperative Blue Cruise and Lane Keeping system with diagnostic trouble code (DTC) U3000:49 with a status byte of -8F- stored in the camera module-rear (CMR). This may be due to the CMR software level. NOTE: The driver status monitor camera module may also be called camera module-rear. |
| 11023713 | 2023 | Quality improvements include: -Enables AM radio -Robustness action to ensure audio presets aren't lost after an Over the Air update |
| 11024366 | 2022,2023 | Quality improvements include: -Calibration update for the Heating Ventilating and Air Conditioning module to prevent window fogging in cold weather |
| 11024522 | 2021,2022,2023,2024 | This article supersedes TSB 25-2104 to update the labor times associated with the Service Procedure. Some of the vehicles listed in the Model statement above may exhibit all of the following conditions: * Inoperative BlueCruise and lane centering * DTC U2018:51 stored in the camera module - rear (CMR) * DTC U0565:86 stored in the image processing module A (IPMA) * DTC U3000:49 is not stored in the CMR This may be due to the software in the CMR. |
| 11024526 | 2021,2022,2023,2024,2025 | Some 2020-2025 various Ford and Lincoln vehicles equipped with blind spot information system (BLIS) may experience an inoperative blind spot monitoring with a "Blind Spot System Fault" message displayed in the instrument panel cluster (IPC). This may also be accompanied by diagnostic trouble codes (DTCs) B118C:11 and/or B118C:15 stored in the driver door module (DDM), and/or B118D:11 and/or B118D:15 stored in the passenger door module (PDM). This may be due to the wiring connector from the mirror to the BLIS module. If diagnostics lead to an internal mirror wiring harness fault, a new lower level BLIS light pigtail is now released for service. It is not necessary to replace the exterior mirror assembly. Use part number SC3Z-14A411-B to resolve the concern. |
| 11024894 | 2023,2024,2025 | Some 2023-2025 Mustang Mach-E vehicles equipped with a lithium iron phosphate (LFP) standard range battery (minor feature code HTHAH) built on or after 23-Jun-2023 may exhibit a condition where the displayed high voltage (HV) battery state of charge (SOC) percentage has a sudden reduction greater than 10% while driving. At low SOC, this may also result in a reduction of vehicle power with a turtle light displayed in the cluster. This concern may occur if the vehicle has not been charged to 100% for an extended period of time as this leads to an inaccurate displayed SOC. Advise customers to charge their vehicle to 100% at least once per month to reset the SOC measurement or more often if the condition persists. To confirm a vehicle is built with a certain minor feature code, review the build information by double-clicking the vehicle identification number (VIN) in the upper left corner in the Professional Technician System (PTS). |
| 11025810 | 2021,2022,2023,2024 | Some 2021-2024 Mustang Mach-E vehicles may exhibit a condition where the interior propulsion sound feature does not remain active and deactivates immediately. This may be due to the audio control module (ACM) configuration. To restore the functionality of this feature, download and run the "ACM - Enable Engine Sound Enhancement and Active Noise Control" application in the Ford Diagnosis and Repair System (FDRS) scan tool. In cases where the ACM is replaced, this routine will run during the "ACM - Programmable Module Installation (PMI)" application. Make sure to follow the FDRS on-screen instructions carefully. For claiming, use causal part 18C869 and labor operation numbers 12651D and 12651D4. |
| 11025811 | 2021,2022,2023 | Some 2021-2023 Mustang Mach-E vehicles equipped with nickel, cobalt and manganese (NCM) standard/extended range battery with minor feature codes HTHAD/HTHAE and 2022-2025 e-Transit vehicles equipped NCM standard range battery with minor feature codes HUKAL/HUKAA may require a high voltage battery module replacement. Technicians can now replace the affected battery module for high voltage batteries with a state of health (SOH) of 70% or higher. It is no longer necessary to replace the complete high voltage battery assembly for vehicles with 70% SOH or higher. Additionally, the battery health chart has been updated to display the actual battery SOH as a percentage and now requires the selection of checkboxes corresponding to the specific high voltage battery module(s) being replaced. After a high voltage battery module replacement and battery reinstallation, relaunch the Ford Diagnosis and Repair System (FDRS) "BECM - Battery Health" application which will prompt for confirmation of a successful repair.<br /><br /> To confirm a vehicle is built with a certain minor feature code, review the build information |
| 11025820 | 2022,2023,2024 | * 2021-2024 Bronco Sport built on or before 15-Dec-2024<br /> * 2022-2024 Mustang Mach-E<br /> * 2022-2025 Escape built on or before 22-May-2025<br /> * 2024 Maverick vehicles built on or after 17-Jan-2024<br /> <br /> Some of the above vehicles may exhibit an illuminated powertrain malfunction (wrench) indicator with diagnostic trouble code (DTC) P0929 stored in the gear shift module (GSM). This may be due to the software in the GSM. To correct the condition, reprogram the GSM module using the latest software level of the Ford Diagnosis and Repair System (FDRS). For claiming, use causal part 7P155 and labor operation numbers 7001D and 7001D4. |
| 11025850 | 2023 | "25S65 Recall remedy -Prevents a potential lock-out condition caused by the vehicle's battery being discharged" |
| 11026511 | 2021,2022,2023,2024,2025 | Some 2021-2025 Mustang Mach-E vehicles may exhibit a condition where the front luggage compartment hood is hard to close. This may be due to an alignment issue with the hood. The most common adjustments to improve closing efforts involve the hood front up and down alignment and the bump stop rubbers. Refer to Workshop Manual, Section 501-03 Body Closures > General Procedures > Hood Alignment for procedures on proper adjustments that can improve front luggage compartment hood closing efforts. |
| 11027123 | 2023,2024,2025 | This article supersedes TSB 25-2189 to update the vehicles affected, production cut-off date and part list. Some of the vehicles listed in the Model statement above may experience exterior paint blistering in at least one of the following areas: * Front and rear door skin panel(s) and door jamb area(s) * Rear quarter panel(s) and jamb area(s) * B-pillar outer panel(s) and jamb area(s) * Roof panel and jamb area(s) * Rocker panel(s) and jamb area(s) This may be due to the factory painting process. |
| 11027715 | 2023,2024,2025 | Some 2023-2025 Mustang Mach-E and 2024-2026 F-Super Duty vehicles equipped with a 360 degree camera may exhibit a distorted or blurry 360 degree camera image in the center display screen, but the rear view camera image is operating correctly. To restore the 360 degree camera image, download and run the "IPMA - Reset the Image Processing Module A (IPMA) Calibration Data" application using the Ford Diagnosis and Repair System (FDRS) scan tool. Then download and run the "IPMA - 360 Degree View Camera Alignment" application. Inform customers that they can continue to drive the vehicle and engineering is currently working on a software solution for this condition that is expected in Q2 2026. Replacement or reprogramming of the IPMA will not resolve this condition. Monitor Professional Technician System (PTS) for additional information and schedule service appointments for customers once the repair becomes available. |
| 11027722 | 2021,2022,2023 | This article supersedes TSB 25-2058 to update: service procedure enhancements, and increase labor operation allowances. Some of the vehicles listed in the Model statement above may exhibit a 12-volt battery drain. This may be due to the software level of various modules such as the gateway module (GWM), accessory protocol interface module (APIM) and driver front seat module (DSM). |
| 11028155 | 2021,2022,2023 | "25S65 Recall remedy -Prevents a potential lock-out condition caused by the vehicle's battery being discharged" |
| 11028164 | 2021,2022,2023 | This article supersedes TSB 25-2156 to update the Service Procedure and Labor Time Allowance. Some of the vehicles listed in the Model statement above may exhibit diagnostic trouble codes (DTCs) C1001:31, U3000:89, and/or U3000:49 stored in the image processing module A (IPMA) and at least one of the following conditions: - "Front Camera Fault Service Required" message - Pre-collision assist inoperative - Adaptive cruise control inoperative - Front windshield camera alignment routine fails to complete This may be due to a connection issue between the IPMA Camera and the IPMA. |
| 11028797 | 2021,2022,2023,2024 | Some 2020-2022-Corsair, 2021-2023 Nautilus, 2020-2024 Navigator/Aviator, and 2021-2024 Mustang Mach-E vehicles equipped with phone-as-a-key may exhibit various phone-as-a-key concerns with diagnostic trouble codes (DTC) U200D:15, U200E:15, U200F:15, B1589:31/49 through B1598:31/49, B1A56:31/49, B1D55:31/49, and/or B15A5:56 stored in the remote function actuator (RFA) module. If any of these DTCs are detected during diagnostics, clear the DTCs, reprogram the RFA to the latest software level and start a new Ford Diagnosis and Repair System (FDRS) session. Verify that DTCs are no longer present. If only the B1589:31/49 through B1598:31/49, B1A56:31/49, B1D55:31/49, and/or B15A5:56 DTCs return in the RFA after a self-test, follow normal Workshop Manual (WSM) diagnostics in Section 419-01. Repair as necessary outside of this article. For claiming, use causal part 14G617 and labor operations 12651D and 12651D4. |
| 11029599 | 2021,2022,2023,2024,2025 | Quality improvements include: - Addresses false warnings attributed to the Off-board Charging Module. These warnings occur due to external charging station failures rather than internal module issues. |
| 11029608 | 2023 | "25S49 Recall Remedy: -Infotainment software update to address frozen screens |
| 11029659 | 2022,2023 | "25S49 Recall Remedy: -Infotainment software update to address frozen screens" |
| 11030596 | 2021,2022,2023,2024 | "26C10 Recall remedy -Addresses instances where the trailer lights and trailer brakes may not function" |
| 11030788 | 2021,2022,2023 | Some 2021-2023 Mach-E and 2022-2024 F-150 vehicles may have customers or dealerships that wish to activate new BlueCruise features (example: Lane Change Assist). New BlueCruise features can only be activated/delivered via an over-the-air update (OTA). Inform customers that they will need to wait for the update to be pushed to their vehicle. There is no way to manually push the update. If the update fails, OTA will re-attempt an update later. |
| 11031263 | 2021,2022,2023,2024,2025 | Various 2020-2026 Ford and Lincoln vehicles equipped with blind spot information system (BLIS) may experience an inoperative blind spot monitoring with a "Blind Spot System Fault" message displayed in the instrument panel cluster (IPC). This may also be accompanied by diagnostic trouble codes (DTCs) B118C:11 and/or B118C:15 stored in the driver door module (DDM), and/or B118D:11 and/or B118D:15 stored in the passenger door module (PDM). This may be due to the wiring connector from the mirror to the BLIS module. If diagnostics lead to an internal mirror wiring harness fault, a new lower level BLIS light pigtail is now released for service. It is not necessary to replace the exterior mirror assembly. Use part number SC3Z-14A411-B to resolve the concern. |
| 11032261 | 2021,2022,2023 | This article supersedes TSB 26-2021. Reason for update: to clarify prior approval requirements in the Service Procedure. Some of the vehicles listed in the Model statement above may exhibit diagnostic trouble codes (DTCs) C1001:31, U3000:89, and/or U3000:49 stored in the image processing module A (IPMA) and at least one of the following conditions: - "Front Camera Fault Service Required" message - Pre-collision assist inoperative - Adaptive cruise control inoperative - Front windshield camera alignment routine fails to complete This may be due to the coaxial cable between the IPMA camera and the IPMA. |
| 11032692 | 2022,2023,2024,2025,2026 | 2022-2026 Mustang Mach-E vehicles built on or after 03-Jan-2022 are no longer equipped with a hands free liftgate system. The vehicle is not misbuilt. The addition of any parts is not a warrantable repair. Do not submit a claim for this condition. |
| 11033807 | 2023,2024 | Quality improvements include: -Addresses a potential communication condition that may result in a loss of radio audio. |
| 11033853 | 2021,2022,2023,2024 | Some 2021-2024 Mustang Mach-E vehicles may exhibit only continuous memory diagnostic trouble code (DTC) U2016:47 stored in the power steering control module (PSCM) after a self test is performed with the Ford Diagnosis and Repair System (FDRS) scan tool. If the vehicle does not exhibit any observable symptoms such as lack of/reduced power steering assist, disabling of power steering assist features and/or power steering assist fault messages displayed on the instrument panel cluster (IPC), this DTC should be ignored. No further service action is required. |
| 11034134 | 2021,2022,2023,2024,2025 | Some of the vehicles listed in the model statement above equipped with SYNC4 may experience a blank center display screen or black center display after welcome animation. The rear-view camera will still function when shifting the vehicle to reverse under these conditions. |
| 11034853 | 2023,2024,2025 | Some 2023-2025 Mustang Mach-E and 2024-2026 F-Super Duty vehicles equipped with a 360-degree camera may exhibit a distorted or corrupted 360-degree camera image in the center display screen, but the rear-view camera image is operating correctly. To restore the 360-degree camera image, download and run the "IPMA - Reset the Image Processing Module A (IPMA) Calibration Data" application using the Ford Diagnosis and Repair System (FDRS) scan tool. Then download and run the "IPMA - 360 Degree View Camera Alignment" application. Inform customers that they can continue to drive the vehicle and engineering is currently working on a software solution for this condition that is expected in Q3 of 2026. Replacement or reprogramming of the IPMA will not resolve this condition. Monitor Professional Technician System (PTS) for additional information and schedule service appointments for customers once the repair becomes available. If a vehicle exhibits this condition, enter a vehicle identification number (VIN) and click the "Submit Global Concern Report (GCR)" link at the upper right of the PTS |
| 11034969 | 2023,2024,2025,2026 | Some 2023-2026 Mustang Mach-E vehicles equipped with a lithium iron/ion phosphate (LFP) standard range battery (minor feature code HTHAH) may exhibit a battery energy control module (BECM) state of health reading that over-estimates the actual high voltage battery state of health after a BECM replacement directed by the Workshop Manual (WSM). This may be due to the software in the BECM. To correct this condition, download and run the "BECM-High Voltage Battery Capacity Relearn" application using the Ford Diagnosis and Repair System (FDRS) scan tool. For claiming, use causal part 10B687 and labor operations 12651D and 12651D4. The engineering team is currently working on a permanent software solution which is expected to be available in Q4 of 2026.<br /><br /> If a vehicle exhibits this concern, submit a Global Concern Report (GCR). To submit a report, click on the "Submit Global Concern Report (GCR)" link at the upper right of the Professional Technician System (PTS) Vehicle ID screen (vehicle identification number VIN required) and fill out the form. Do not use the "Report A Problem" link to submit |
| 11035097 | 2021,2022,2023,2024,2025,2026 | Some of the vehicles listed in the Model statement above may exhibit a distorted or muffled sound originating from the center speaker. This may be due to a deformed speaker cone. |
| 11035100 | 2021,2022,2023,2024,2025,2026 | Some 2021-2026 Ford vehicles may exhibit inoperative heated/cooled seats, heated steering wheel and/or front/rear defrost features after a remote start is performed through the Ford mobile application or with the key fob. Customers may also experience heated/cooled seats, heated steering wheel and/or front/rear defrost features turning on in unexpected conditions such as during warmer weather. These features will operate normally when commanded in the center display screen. This may be due to the customer not setting up their "Climate Settings" through the Ford mobile application. To correct this condition, inform the customer they should perform a remote start from the Ford mobile application and then adjust the "Climate Settings" in the Ford mobile application as desired. These settings only need to be set once and will persist through subsequent remote starts. Heated and cooled seats will be set to Level 2 when turned ON via "Climate Settings" in the Ford mobile application during a remote start event. This is normal operating characteristic. This condition does not affect vehicle durability and no a |
| 11035267 | 2021,2022,2023,2024 | Some 2021-2024 Ford and Lincoln vehicles may exhibit an "Updating SYNC" message on the vehicle center display screen after an over the air (OTA) update. The message can be cleared from the center display screen and SYNC can be used normally, but it will re-appear at every subsequent ignition cycle. Inform customers that engineering is currently working on a software update solution for this condition to be delivered OTA expected in late Q3 2026. Software will update automatically if vehicle connectivity is enabled in the vehicle-s settings. Monitor Professional Technician System (PTS) for additional information. |
| 11035269 | 2021,2022,2023,2024,2025,2026 | Some 2021-2026 Ford/Lincoln vehicles may exhibit various symptoms including but not limited to the auto start/stop system not operating as intended with a "Check Charging System" message in the instrument panel cluster (IPC) while the charging system is operating properly with no charging related diagnostic trouble codes (DTC) stored. This may be due to someone using an aftermarket programmer to change the body control module (BCM) configuration to disable the auto start/stop system or perform other unsupported programming modifications. To correct this condition on F-150 and Bronco vehicles, download and run the Ford Diagnosis and Repair System (FDRS) application titled "BCM-Charging System Configuration Correction". Running this application will determine if the BCM configuration was modified by the customer and if so, provide the option to return the configuration back to factory settings. For other vehicle models exhibiting concerns related to unsupported aftermarket BCM programming, submit a Technical Support Request (TSR) requesting support to revert the BCM configuration |
| 11035301 | 2023,2024,2025,2026 | Some 2023-2026 Mustang Mach-E vehicles equipped with a lithium iron/ion phosphate (LFP) standard range battery (minor feature code HTHAH) may exhibit a battery energy control module (BECM) state of health reading that over-estimates the actual high voltage battery state of health after a BECM replacement directed by the Workshop Manual (WSM). This may be due to the software in the BECM. To correct this condition, download and run the "BECM-High Voltage Battery Capacity Relearn" application using the Ford Diagnosis and Repair System (FDRS) scan tool. For claiming, use causal part 10B687 and labor operations 12651D and 12651D4. The engineering team is currently working on a permanent software solution which is expected to be available in Q4 of 2026. If a vehicle exhibits this concern, submit a Global Concern Report (GCR). To submit a report, click on the "Submit Global Concern Report (GCR)" link at the upper right of the Professional Technician System (PTS) Vehicle ID screen (vehicle identification number VIN required) and fill out the form. Do not use the "Report A Problem" link to submit a report for |
Sources and import record
- recalls — 5 matching or returned records in the saved snapshot.
- complaints — 115 matching or returned records in the saved snapshot.
- investigations — 2 matching or returned records in the saved snapshot.
- manufacturer-communications-data-dictionary — 0 matching or returned records in the saved snapshot.
- manufacturer-communications-2010-2014 — 0 matching or returned records in the saved snapshot.
- manufacturer-communications-2015-2019 — 0 matching or returned records in the saved snapshot.
- manufacturer-communications-2020-2024 — 113 matching or returned records in the saved snapshot.
- manufacturer-communications-2025-2026 — 65 matching or returned records in the saved snapshot.
Charging, Tech & Ownership Notes
- Mustang Nite Pony Package 55R used black wheels and badging on Premium Extended Range and GT Performance Edition configurations.
- Ford announced future NACS adapter and software integration; actual adapter eligibility and installed software must be checked separately.
Special Models
Mustang Nite Pony Package
| Production | No separate verified count appears in the inspected sources. |
|---|---|
| Identity | A black-wheel and badging package for supported Premium Extended Range and GT Performance configurations. |
| Package code | 55R |
| Count status | Not published |
GT Performance Edition
| Production | No separate verified count appears in the inspected sources. |
|---|---|
| Identity | A GT-based factory performance configuration with 634 lb-ft, MagneRide, and dedicated chassis content. |
| Package code | 60P |
| Final EPA range | 260 miles |
Related Stories
Trivia & Notes
- The final 312-mile California Route 1 eAWD record was the longest-range configuration in the inspected 2023 U.S. certification catalog.
Owner Finds
As an Amazon Associate MustangCarFacts.com earns from qualifying purchases. These links open Amazon searches, so verify fitment, licensing, seller, price, and availability before buying.
All-Weather Floor Mats
A practical first buy for an EV daily driver, especially if the car sees commuting, kids, pets, or rainy charging stops.
Shop 2023 Mustang Mach-E all weather floor matsCargo Liner
Protects the rear cargo area from charging gear, road-trip luggage, groceries, and the usual hatchback life.
Shop 2023 Mustang Mach-E cargo linerCharging Cable Organizer
Keeps mobile charging cables and adapters from turning the cargo floor into a knot of EV spaghetti.
Shop 2023 Mustang Mach-E charging cable organizerMach-E Key Fob Cover
A low-cost way to protect the fob while adding a little color or Mustang identity to everyday carry.
Shop 2023 Mustang Mach-E key fob coverMach-E Car Cover
A good fit for owners storing the car indoors, parking under trees, or trying to keep the gloss-black trim looking sharp.
Shop 2023 Mustang Mach-E fitted car coverSources
- FuelEconomy.gov 2023 Ford Mustang Mach-E configuration records
- Ford battery-capacity and chemistry plan
- Ford 2022 Mustang Mach-E technical specifications
- Ford Division 2023 Mustang Mach-E U.S. Job 2 order guide
- Ford 2023 Mustang Mach-E technical specifications
- Ford EV customers to gain access to Tesla Superchargers and future NACS ports
- Ford Motor Company Q4 and full-year 2023 U.S. sales and production report
- Ford introduces the all-electric Mustang Mach-E family
